| Enclosure | Bass reflex type |
|---|---|
| Rated Input | 30 W (High Impedance) |
| Power Handling Capacity | Continuous pink noise: 60 W (8 Ω), 30 W (16 Ω) |
| Impedance (70 V line) | 170 Ω (30 W), 330 Ω (15 W), 1 kΩ (5 W), 3.3 kΩ (1.5 W), 10 kΩ (0.5 W) |
| Impedance (25 V line) | 170 Ω (3.7 W), 330 Ω (1.9 W), 1 kΩ (0.6 W), 3.3 kΩ (0.2 W), 10 kΩ (0.06 W) |
| Sound Pressure Level | 90 dB (1 W, 1 m) |
| Frequency Response | 70 – 20,000 Hz |
| Speaker Component | High frequency: Balanced dome-typeLow frequency: 12 cm (5") cone-type |
| UL Code | UL1480 (UEAY), UL2043, CAN/CSA C22.2 No.205 (UEAY7) |
| Mounting Hole | ø200 mm (7 7/8") Maximum ceiling thickness: 37 mm (1 29/64") |
| Input Terminal | Removable locking connector with screw-down terminals (2 input terminals and 2 bridge terminals) |
| Usable Cable | Specifications |
| Solid copper wire | ø1.0 – ø1.6 mm (equivalent to AWG 18 – 14) |
| Stranded copper wire | 0.75 – 2.5 mm2 (equivalent to AWG 18 – 14) |
| Finish | Specifications |
| Enclosure | Steel plate, plating |
| Baffle | Fire-resistant ABS resin (resin material grade: UL-94 V-0 or its equivalent), black |
| Rim | Fire-resistant ABS resin (resin material grade: UL-94 V-0 or its equivalent), white, paint |
| Punched net | Steel plate, white, paint |
| Dimensions | ø230 mm (9 1/16") x Depth 209 mm (8 15/64") |
| Weight | 8.1 lbs (including mounting accessories) |
| Shipping Weight (Pair) | 16.2 lbs (including mounting accessories) |
