The HA-1060EN is a highly efficient, long-range horn-array speaker designed to deliver clear, intelligible voice communication across large outdoor areas. Composed of multiple horn speakers positioned in an array, it delivers focused sound projection that allows announcements, paging messages, and emergency notifications to be heard clearly over long distances without the need for acoustic correction. A built-in high-pass filter helps protect the speaker by reducing low-frequency content that could cause damage.
Designed for permanent outdoor installations, the HA-1060EN features an IP66-rated weatherproof enclosure, a double drip-proof structure, and a salt-resistant paint finish for reliable operation in harsh environmental conditions. Its wide horizontal coverage makes it ideal for stadiums, transportation facilities, industrial sites, campuses, public venues, and other large-area public address applications where speech intelligibility is critical.
Certified to EN 54-24:2008 and compliant with BS 5839-8:2008 standards, the HA-1060EN is suitable for voice alarm and evacuation systems that require dependable performance and consistent coverage. Its durable construction, efficient design, and optional mounting bracket make it a versatile solution for outdoor communication systems where long-term reliability and clear voice projection are essential.
| Rated Input | 60W |
|---|---|
| Rated Impedance | 100V line: 170Ω (60W), 330Ω (30W) 70V line: 83Ω (60W), 170Ω (30W) |
| Sensitivity | 111 dB (1W, 1m) (500 Hz - 5 kHz, IEC60268-5) |
| Max. SPL | 128 dB (60W, 1m) (500 Hz - 5 kHz, IEC60268-5) |
| Frequency Response | 520 Hz - 4.6 kHz (-10 dB), 350 Hz - 11 kHz (-20 dB) |
| Speaker Component | Horn speaker unit x 8 |
| Input Terminal | Ceramic terminal (3-pole), can be bridge-connected x1, Ceramic terminal (2-pole) x 1, Thermal fuse is included |
| Cable Gland | Size: PG 13.5 - 12 (gray) x 1, Cable Diameter Range: 12.5 - 6.5 mm ( 0.49" - 0.26") Size: PG 13.5 - 08 (black) x 1, Cable Diameter Range: 9 - 4.5 mm ( 0.35" - 0.18"), Two cable glands are factory-installed |
| Speaker Cable | Attached 4-core cable, 2 m (6.56 ft) |
| Compatible Wire | For Ceramic terminal (3-pole), Conductor: Solid wire or 7-core wire No bridge connection: 0.8 - 10 mm² (AWG 18 - 7) for solid wire, 0.8 - 8 mm² (AWG 18 - 8) for 7-core wire Bridge connection: 0.8 - 2.5 mm² (AWG 18 - 13) for solid wire, 0.8 - 1.5 mm² (AWG 18 - 15) for 7-core wire |
| IP Code | IP66 |
| EN 54-24 Specifications | Sensitivity: 89 dB (1W, 4m), Max. SPL: 106 dB (60W, 4m) Coverage Angle (-6 dB): Horizontal: 190° (500 Hz), 165° (1 kHz), 85° (2 kHz), 45° (4 kHz) Vertical: 40° (500 Hz), 25° (1 kHz), 15° (2 kHz), 15° (4 kHz) Environmental Type: B (outdoor applications) IP Code: IP33C |
| Operating Temperature | -20°C to +55°C (-4°F to 131°F) |
| Finish | Case: Aluminum, white (RAL 9016 equivalent), salt-resistant, paint Front grille: Aluminum, white (RAL 9016 equivalent), paint, Bolts: Stainless steel |
| Optional Accessories | Speaker mounting bracket: YS-1100A |
| Dimensions (H x W x D) | 48.54" (1233 mm) x 6.57" (167 mm) x 5.53" (140.5 mm) (excluding projection) |
| Weight | 30.86 lbs (14 kg) (unit only) |
