West Penn 25226B 14/2 Plenum Audio Speaker Wire - White (1000ft)

Part # 25226BWH1000
Model # 25226B
The West Penn 25226B is a 1000 ft 14 AWG plenum-rated speaker cable with stranded bare copper conductors and a flexible white jacket. Features two conductors with red and black insulation, ideal for commercial audio, paging, and fire-alarm systems.
Availability: Usually arrives in 5-9 business days.

Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email [email protected] or call us at 888-256-4112.

Description

Details

West Penn 25226B 14/2 White Plenum Audio Speaker Wire

The 25226B 1000 ft white plenum-rated speaker cable provides professional-grade performance for commercial and low-voltage installations. It features 14 AWG stranded bare copper conductors for excellent signal integrity and flexibility. Each conductor is insulated with red and black PVC, enclosed in a durable, fire-resistant white plenum jacket suitable for ducts, plenums, and walls.

Designed for easy installation and reliable long-term use, the 25226B includes sequential footage markings for precise measurement. It is perfect for audio distribution, paging systems, and fire-alarm wiring in commercial buildings, ensuring safety and clear signal transmission in plenum spaces.

Features

Features

  • 1000 ft white jacketed cable for indoor use
  • 14 AWG stranded bare copper conductors
  • 2 conductors with red and black insulation
  • Plenum-rated for ducts, plenums, and walls
  • Flexible PVC jacket for easy routing and installation
  • Sequential footage markings for quick and accurate measurement
  • Available in a tangle-free box or spool
  • Ideal for commercial audio, paging, and fire-alarm systems
Specification
Cable Length1000 ft
Jacket ColorWhite
Conductor Size14 AWG
Number of Conductors2
Conductor MaterialStranded Bare Copper
Conductor Stranding19 x 27
Insulation TypePlenum PVC
Insulation ColorsRed and Black
Jacket TypeFlexible Plenum PVC
Jacket Thickness0.015"
Cable Outer Diameter0.223"
Nominal DCR2.7Ω per 1000 ft
Voltage Rating300V
UL/NEC RatingCL3P, FPLP
Flame RatingNFPA 262 Plenum
Operating Temperature0°C to 60°C
Bend Radius2.007"
Pull Tension84 lbs
RoHS CompliantYes
Typical ApplicationsAudio, control, and low-voltage power in plenum spaces
