Williams AV AN C5P Annotation Pro Plus Video Processor

The AN C5P Annotation Pro Plus is a professional, hardware-based video processor, designed so that users can display content from video and computer sources connected directly to the Annotation Pro. Users can write annotations and markers directly on the video content to help explain any content.

The Annotation Pro Plus includes support for HDCP.

Features

Features

Industry's First True 4K Annotation System
HID Touchscreen Support
4K HDMI I/O, USB 3.0, Integrated 4-Port USB Hub
Professional Annotation Graphics with Intuitive Navigation Toolbar or Hidden Corner Support
HDCP Support

Specification

Video Input	HDMI up to 3840 x 2160 @ 24/25/30 fps
Video Output	HDMI up to 3840 x 2160 @ 60 fps
USB	(5) USB 3.0 ports, plus (1) USB B-Micro port
Power Source	TFP 060 - 19VDC 4.7A (center positive)
Temp Operating Requirements	32°F to 122°F (0°C to 50° C)
Dimensions (H x W x D)	1.75” (44.5 mm) x 19" (483 mm) x 8.2" (208 mm)
Weight	5 lbs (2.3 kg)
