Williams Sound DWD 102 Digi-Wave Dual-Bay Docking Station (Discontinued)

Description

Williams Sound DWD 102 Digi-Wave Two Bay Docking Station

The Digi-Wave™ Dock offers an innovative extension to the Digi-Wave two-way, wireless communication system from Williams Sound.  It provides a simple, flexible way to connect portable Digi-Wave systems to other fixed systems.  The connection begins when a Digi-Wave transceiver or receiver is simply plugged into the Dock. The Digi-Wave Dock provides continuous power and/or charging for two Digi-Wave devices and has separate audio inputs and outputs in each of its bays.

The Digi-Wave Dock adds even greater flexibility to an already flexible Digi-Wave platform. Use the Dock to…

• Create a multi-presenter Digi-Wave presentation system without the need for a mixer or multiple wireless microphones

• Generate a wireless extension by connecting a Digi-Wave system to a teleconferencing or wired intercom system
• Easily connect and power individual interpreter transmitters, when a Digi-Wave is used in language interpretation mode
• Facilitate an array of other applications -- applications limited only by one’s imagination

Features

• Easy access to all sound systems
• Separate inputs and outputs in each bay RCA or XLR input/output option
• Charges DLT 300, DLT 100 2.0 transceivers or DLR 360, DLR 60 2.0 receivers
• Clean, streamlined design

Specifications

Enclosure	Black, heavy duty plastic molded top, with metal base and non-skid rubber feet, White legends on back
DC Power Input	2.5 mm ID barrel connector, 24VDC input, 750mA, Center Positive
Power Supply	Williams Sound TFP 048 Input: 100-240VAC 50/60Hz, 18W Output: 24VDC, 750mA
Charging Time	DLT 100 2.0: 5 hours nominal (internal Lithium Polymer Battery) DLR 60 2.0: 5 hours nominal, based on Williams Sound NiMH battery BAT 022-2
Unit Capacity	2 Units: DLT 100 2.0, DLR 60 2.0, or DLR 60. DLT 100 units will charge only (no audio)
Indicators	Green LED indicating power at the charger/dock. Charging status is shown on unit being charged
Rear Inputs	One set of female L/R RCAs and one female XLR per bay
Rear Outputs	One set of L/R RCAs and one male XLR per bay
Dock Connector	One 30-pin connector per bay. Supports power/charging, audio in, audio out, and control signals
Controls	One 2-position switch per bay, for "manual" or "auto" mode
Dimensions (H x W x L)	2.16" (55 mm) x 4.34" (110 mm) x 8.88" (226 mm)
Shipping Weight	1.4 lbs (0.64 kg)

DOCUMENTS

In The Box

• (1) DWD 102 Digi-Wave™ Dual-Bay Docking Station
• (1) TFP 048 Power Supply
• (1) WLC 004 Line Cord (U.S.)
• (2) WCA 078 Stereo RCA Cables
• (4) RBP 005 Support Pads 1/8" (Thick)
• (4) RBP 006 Support Pads 1/16" (Thin)
