The Williams Sound DWS TGS 10 2.0 Digi-Wave PortableTour Guide System 10 is a one-way, wireless tour guide system in the 2.4 GHz band. It is ideal for smaller tour groups of 10 or fewer members. Enhances communication between tour guide and group members. Helps overcome background noise and distance from the tour guide. The system can be used in factories, museums, tourist attractions, or bus tours. Group members have listen-only capabilities.
| Color | Black and silver |
|---|---|
| Enclosure | Shatter resistant PC/ABS plastic |
| Battery type | Li Polymer with smart charge built into transceiver |
| Battery life | Up to 14hrs talk time per charge |
| Charge time | 5hrs. TFP 045 with cable and international adapters Optional two-bay charger CHG 102 |
| Channels | Up to 15 simultaneous channels (Interpretation mode); Up to 4 simultaneous groups (2 way mode) |
| Operating frequencies | 2.4GHz (ISM band) 2.402 – 2.476GHz FHSS |
| Frequency response | 150 – 11KHz |
| S/N ratio | 69dB (A weighted) |
| THD | 0.33 % |
| Microphone input | Internal microphone & 3.5mm stereo jack w/ electret microphone bias, adjustable gain with 63dB range |
| Audio output | Max SSPL 90 111.8dB (EAR 013), 116.8dB (EAR 041), Internal speaker, 16mW @ 33Ω |
| Range | Up to 100ft outdoors and 200ft indoors |
| Modulation | GFSK, binary CDMA |
| RF output | 14dBm Max |
| Security code | 87 bit encryption |
| Output | 3.5mm stereo/mono jack 30 pin charging jack |
| Side tone | Adjustable: Off (0dB), -6dB, -12dB below volume |
| Speaker | Internal speaker (disabled when ear jack is engaged) |
| Indicators | LCD (Group, channel, volume level, battery status, mode, signal strength) |
| LED’s | Red LED around talk button when enabled. Amber LED signifying voting feature activated |
| Maximum presenters | Two presenters at any given time |
| Dimensions (H x W x D) | 4.1" (103 mm) x 2.4" (62 mm) x 0.4" (11 mm) |
| Weight | 0.18 lb (0.08 kg) including battery |
| Frequency Band | 2.4GHz (ISM band) |
| Modulation | GFSK digital transmission |
| Range | Up to 100ft outdoors, up to 200ft indoors |
| Multi Channel | Up to 15 simultaneous channels (one way mode) |
| Maximum presenters | Two presenters at any given time (two way mode) |
| Battery life | Alkaline Disposable (BAT 010-2): Up to 27 hrs; NiMH Rechargeable (BAT 022-2): Up to 21 hrs |
| Battery type | 2 x AAA Alkaline or NiMH |
| Frequency response | 150 – 11Khz |
| S/N ratio | 65dB (A weighted) |
| THD | 0.45% |
| Dimensions (H x W x D) | 3.54" (90 mm) x 2.36" (60 mm) x 0.63" (16 mm) |
| Weight | 0.11 lb (0.05 kg) |
| Color | Black |
| Plug | 2 x 3.5mm |
| Cord | 39" |
| Phantom Powered | No |
| Nominal Impedance | 32Ω |
| Freq. Response | 150 - 18kHz |
| Pick-Up Pattern | Cardiod |
| Transducer Type | Electret Cond |
| Sensitivity | 105dB EAR |
| Replacement Windscreen | WND 008 |
| Replacement Earpad | EAR 035 |
| Weight | 0.16 lb (0.07 kg) |
| Style | Around-ear speaker |
| Plug | 3.5mm mono |
| Cord | 39" |
| Driver Size | 0.91" (23 mm) |
| Nominal Impedance | 32Ω |
| Freq. Response | 20 - 20kHz |
| Max Power Input | 30 mW |
| Sensitivity | 118 dB @ 1kHz |
| Weight | 0.03 lb (0.02 kg) |
| Dimensions (H x W x D) | 4.38" (109 mm) x 2.75" (70 mm) x 0.5" (13 mm) |
| Weight | 0.11 lb (0.05 kg) |
| Dimensions (H x W x D) | 18.25" (464 mm) x 7.0" (178 mm) x 14.13" (359 mm) |
| Weight | 6.80 lbs (3.08 kg) |
