| Built-in pads | 12 |
|---|---|
| External inputs | 5 (three-zone x 1; monaural x 4) |
| Maximum Polyphony | 64 notes |
| Voices | Drum and percussion: 1,061 Keyboard: 216 |
| Effects | Variation x 42 types; Chorus x 6 types; Reverb x 6 types: 5-band master equalizer |
| Drum kits | Preset: 50 User-defined: 200 |
| Wave memory | 100 MB (16-bit linear conversion) |
| Note Resolution | Quarter note / 480 |
| Patterns | Preset patterns: 128 phrases (including 3 demo patterns) User-defined patterns: 50 phrases |
| Sequence formats | Proprietary SMF Format 0 (for loading only) |
| Sequence capacity | 152,000 notes |
| Recording method | Real-time overdubbing |
| Readable quantity | 500 |
| Bit depth | 16 bit |
| Wave memory | 64 MB |
| Maximum size | Mono sample: 2 MB Stereo sample: 4 MB |
| Sample formats | Proprietary, WAV, and AIFF |
| Display | Backlit LCD with 2 rows of 16 characters |
| Connectors | PAD (13) jack (standard stereo-phone plug |
| Power Consumption | 9W (DTXM12 and PA-5D adaptor) |
| Package Contents | Power adaptor (PA-5D or an equivalent recommended by Yamaha), Owner's Manual , Data List booklet |
| Pad functions | Increment or decrement of drum kit, pattern, or tempo; tap tempo |
| Tempo | 30 to 300 BPM. Tap tempo functionality |
| Beats | 1/4 – 16/4, 1/8 – 16/8, 1/16 – 16/16 |
| Note timing | Accent notes, quarter notes, eight notes, sixteenth notes, triplets |
| Dimensions | Width: 345mm Height: 96mm Depth: 319mm |
| Weight | 7.27 lbs (3.3 kg) |
Usually arrives in 5-9 business days.
