Yamaha DXS18 18" Powered Subwoofer

Name: Yamaha DXS18 18" Powered Subwoofer
Brand: Yamaha
SKU: YAMAHA-DXS18
Price: 1534.99 USD
Availability: InStock
Rating: 5 (1 reviews)

Write a Review

Part #:

DXS18

Model #:

DXS18

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The DXS 18 achieves best in class SPL of up to 136dB and delivers the lowest frequency 32Hz in the lineup. Equipped with a band-pass type enclosure and high power handling 4-inch voice coil magnet that drives the 18-inch woofer, the Class-D amplifier delivers 1020W of power with exceptional clarity and accuracy.

Description

The DXS Series are compact, high-output, powered subwoofers that match perfectly with DSR, DXR and DBR full-range powered loudspeakers, and feature intelligent DSP technologies that enhance the versatility in its performance.

The DXS Series has a band-pass design that produces extremely high SPL by drastically reducing the distortion. The DXS features a customized, high-power handling woofer with superior damping for a clean, accurate delivery of the massive power produced by a 1020W Class-D high-efficiency amplifier. What’s more, Yamaha’s formidable DSP technologies are perfectly utilized in the DXS Series for precise tuning of filters and low-frequency response, as well as high-grade protection functions that ensure all components perform to the full limit of their potential. The unmistakable result is clearly defined, powerful bass frequencies that will take your sound system to new heights... and depths.

Features

Portable 18" subwoofer with 800-watt RMS power amp
18" long-throw speaker with a 2.5" voice coil for superb bass response
32Hz-120Hz frequency range is ideal for small- to medium-sized rooms
Built-in D-XSUB processing allows you to extend the frequency response even lower
Wooden cabinet is durable and acoustically optimized for maximum sound quality

Specifications

Frequency Range (-10dB)	32Hz - 120Hz
Components (LF)	Diameter: 18" cone, Voice Coil: 4"
Output Power	Dynamic: 1020W / Continuous: 800W
Maximum Output Level (1m; on axis)	136dB SPL
I/O Connectors	INPUT: XLR-3-31 x2 , THRU: XLR3-32 x 2 (THROUGH or HPF POST)
Processors	D-XSUB: BOOST, XTD LF, NORMAL
1/8 Power Consumption	100W
Power Requirements	100V - 240V, 50Hz/60Hz
Pole Socket	35mm (Top x 1)
Material	Wood (Paint, Black)
Dimensions (H x W x D)	26.8" (683 mm) x 22.2" (563 mm) x 28.4" (721 mm)
Weight	110 lbs (49.7 kg)
