Yamaha MGP24X 24 Channel Premium Analog Mixing Console

Part #:
MGP24X
Model #:
MGP24X
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Yamaha MGP24X 24-channel analog mixing console with DSP effects can easily adapt to a truly impressive range of applications from portable PA to fixed installation.

Description

The Yamaha MGP24X mixing console can easily adapt to a truly impressive range of applications from portable PA to fixed installation. It has technological innovations in sound quality, reliability, functionality with cutting-edge digital technologies.

Drawing from our decades of experience crafting innovative, premium analog gear, we originally developed our new discrete Class-A microphone preamps for professional use in our high-end recording equipment. Utilizing an inverted Darlington circuit design, our newly-refined D-PRE mic preamps deliver a fat, rich, smooth tone that gives the MGP Series a significant advantage over any other mixer in its class. With Yamaha's proprietary X-pressive EQ we've managed to capture ultimate analog authenticity by unlocking the mysterious secret behind the expressive sound shaping capabilities of sought-after classic EQ modules.

At the heart of the MGP's compact configuration, we've taken an innovative new approach to the utilization of digital technology in an analog mixer; adding high-resolution effects, iPod/iPhone integration and the superb functionality of our new Stereo Hybrid Channel to the warmth and musicality of premium analog sound. The MGP Series represents the ultimate balance of the converging technologies that are the heart and soul of Yamaha's extraordinary achievements in professional audio.

When it comes to audio engineering and sound reinforcement, the verdict is in—nothing beats the warmth and musicality of analog sound. By incorporating state-of-the-art digital technologies into the development process of our premium professional analog equipment, the MGP is the next step in the evolution of compact professional mixers.

Features

  • 16 Mic Inputs with 48V Phantom Power and HPF per Channel
  • 24 Line Inputs (16 mono and 4 stereo)
  • 6 AUX Sends + 2 FX Sends
  • 4 GROUP Buses + ST Bus
  • 2 Matrix out
  • 1 Mono out
  • 1-Knob Compressors
  • Internal Universal Power Supply
  • A Revolution in Digital
  • Dual Digital Effects
  • Graphic EQ
  • Multi-band Compressor
  • High-Quality Digital Playback
  • USB Device Recording and PlayBack

Specifications

Mixing Capability
Mixing Channels 24 Line Inputs (16 mono and 4 stereo)
GROUP 4 GROUP Buses + ST Bus
AUX 6 AUX Sends + 2 FX Sends
MATRIX 1 Matrix out
On-Board Processors FX1:REV-X (8 PROGRAM, PARAMETER control)/ FX2:SPX (16 PROGRAM, PARAMETER control)
I/O
Mic Inputs MIC: 16 (INPUTS HPF: 100Hz 12dB/oct)
Phantom Power 48V phantom power per channel
Line Inputs LINE: 16 mono + 4 stereo, CH INSERT: 16 RETURN: 1 stereo
Digital I/O USB Device, iPod / iPhone
General
Total Harmonic Distortion 0.02% (20Hz-20kHz@ +14dBu)
Frequency Response +0.5/-1.0dB 20Hz - 20kHz, refer to the nominal output level @1kHz
Hum & Noise Level
Equivalent Input Noise -128 dBu Equivalent Input Noise
Residual Output Noise -94 dBu Residual Output Noise
Crosstalk -74dB @ 1kHz
Power Requirements 100-240V 50Hz/60Hz
Power Consumption 86W max
Dimensions (H x W x D) 6.7" (169 mm) x 32.2" (819 mm) x 22.2" (565 mm)
Net Weight 34.2 lbs (15.5 kg)
