The PSA1SF Paraline Series 2x12" powered subwoofer is engineered for medium-sized events and scalable array systems that require compact size with high-output performance. Delivering 2800 watts of peak power and 1400 watts program, the PSA1SF provides tight, controlled low-frequency reinforcement down to 37 Hz.
Equipped with dual 12" woofers featuring 3" voice coils, this powered subwoofer uses a high-efficiency Class D amplifier and a precision-tuned bass reflex cabinet to maximize output while maintaining clarity and reliability. Its solid 15 mm birch cabinet construction ensures durability for demanding live sound and installed applications.
As the flyable version of the PSA1S, the PSA1SF is specifically designed for flown array configurations where ground-stacked subwoofers are not practical. It integrates seamlessly with PSA1 powered loudspeakers, making it ideal for professional touring systems, event production, and permanent installations requiring elevated low-frequency coverage.
| System Type | Powered Subwoofer |
|---|---|
| Program Power | 1400 Watts Program (2800 Watts Peak) |
| Max SPL | 135 dB Peak (129 dB Continuous) |
| Frequency Response | 100 Hz (Hz +/- 3 dB) |
| Crossover Frequency | Fixed @ 100 Hz |
| Cabinet Configuration | Bass Reflex Cabinet |
| LF Driver | 2x12" Ceramic with 3" Voice Coil |
| LF Impedance | 2x4 Ohm Load |
| LF Power Amplifier (Watts) | Class D |
| Power Consumption | 210 VA/440 VA |
| Inputs | 1x XLR Input, 1x 1/4" Input |
| Controls | Line/Speaker Mode |
| Master Volume Control | Level |
| LED Indicators | Clip, Limit, Power |
| Wheels | 2 (Rear Tilt-back) |
| Bar Handles | 2 (1x Each Side) |
| Eyebolts for Rigging/Flying | 4x EYEBOLT3/8A |
| Enclosure/Baffle Materials | 15 mm Birch |
| Covering/Finish | Paint |
| Dimensions (H x W x D) | 32" (812.8 mm) x 14" (355.6 mm) x 22.8" (579.12mm) |
| Weight | 120 lbs (54.6 kg) |
