The JBL Control 24CT Micro Plus is a 4" two-way vented in-ceiling speaker that is ideally suited for a wide variety of applications, from restaurants and specialty retail stores to professional offices and airports. Low distortion, a smooth, natural frequency response, and a 25W transformer make the Control 24CT Micro Plus ideal for medium volume business music.
Low frequency output can be augmented with the addition of one of the Control Contractor subwoofer models. Similar mid/high frequency voicing to other JBL Control Contractor loudspeakers allows mixing and matching of models within zones without requiring separate equalization.
Installation of the Control 24CT Micro Plus is quick and easy. The loudspeaker is packaged with the backcan, grille, support backing bracket and tile rails. In addition, optional new construction brackets are available. The entire installation can be accomplished without requiring access above the ceiling. The Control 24CT Micro Plus backcan is made of formed steel and the speaker is suitable for use in air handling spaces per UL2043. An attachment loop is provided on the backcan for cabling. A seismic tab is provided as a secondary support. The Control 24CT Micro Plus trim and baffle are paintable to match any decor.- Features
Features
- Extremely wide 150° coverage
- Smooth frequency response
- Advanced crossover network provides very even coverage throughout listening area
- 4.5" woofer, injection molded graphite cone with butyl rubber surround
- 0.5" polycarbonate tweeter for extended response
- Includes 25W multi-tap transformer for 70V/100V systems
- Shallow 4" depth
- Packaged with grille, backcan and tile rails for fast installation and easy dealer stocking
- Specification
Frequency Range (-10 dB) 80 Hz - 25 kHz Nominal Sensitivity 85 dB SPL @ 1 m (3.3 ft) Crossover 3.5 kHz, 3rd order low-pass plus 3rd order high-pass with conjugate Rated Maximum SPL 99 dB @ 1 m (3.3 ft), 25W tap Transformer Taps 70V: 25W, 12W, 6W taps
100V: 25W, 12W tapsLow Frequency 4.5" IMG (injection molded graphite), 1" voice coil High-Frequency 0.5" polycarbonate Backcan Formed steel Baffle/Rim Medium impact polystyrene, fire rated UL94V-O, Secondary Attachment Point: Included Termination Screw-down terminals, touch-proof, UL, CE and VDE rated, outside of backcan with conduit cover Safety Agency Rating Suitable for use in airhandling spaces, per U.L.-2043, U.L.-1480, NFPA90, NFPA70A Cutout Size 6.6" (167 mm) Dimensions (H x Dia) 5.3" (133 mm) x 7.7" (195 mm)
4.1" (105 mm) from front of ceiling tile to the back of the backcanNet Weight (ea) 5.5 lbs (2.5 kg) Shipping Weight (Pair) 17 lbs (7.6 kg) - Documents
