Description

Details

TOA Electronics NM-01 Noise Masking Module for TOA's 9000M2, 900, 700 and BG-2000 Series Amplifiers

This module generates a noise source to be used for sound masking and audio privacy applications. Such applications include open-plan office environments or smaller spaces where distracting or private conversations need to be made unintelligible. The module allows connection of optional external signal processing equipment (e.g. an equalizer), as required. A simple contact allows for muting of this noise source, if desired.

Features

Features

Generates band-limited pink noise for use in sound masking applications
In/Out processor loop for external EQ
Compatible with TOA modular mixer-amps (BG-1000/2000, 700, 900MkII, 9000M2)

Specification

Power Source	24 V DC (Supplied from amplifier)
Current Consumption	10mA
Output Level (to Amplifier)	300mV
Noise Type	Analog random pink noise
Mute Function	Dry contact, normally open (close to mute)
Input	10kΩ, RCA pin jack
Output	150mV, 600>, RCA pin jack
Supplied Accessory	Stereo RCA cable
Dimensions (H x W x D)	3.07" (78 mm) x 1.38" (35 mm) x 3.46" (88 mm)
Weight	0.14 lbs (64 g)
