Alto TRUESONIC TS115A 800W 15" Loudspeaker (Discontinued)
Part # TS115A
Model # TS115A

The Alto TS115A TRUESONIC 15 inch Loudspeaker has been designed with verstility and longevity in mind. It features a durable, lightweight polypropylene enclosure that is stand mountable for weekend gigs and flyable for more permanant installations.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

The Alto TS115A TRUESONIC 15 inch Loudspeaker has been designed with verstility and longevity in mind. It features a durable, lightweight polypropylene enclosure that is stand mountable for weekend gigs and flyable for more permanant installations. What's more, it has a trapezoidal design which greatly decreases the resonance of the standing wave in the cabinet for a more true and exact sound reproduction. The Truesonic TS115 is the perfect solution for musicians and DJs on the move and halls, malls, and houses of worship alike.

The Truesonic Series was designed from the ground up to be the most transparent loudspeaker money can buy. Rigorous testing and thousands of hours of listening have gone into making sure that what you pump into a Truesonic speaker is exactly what you get out. Everything you see (and some things you don’t) – from internal signal path and components used to the sculpted cabinet and meticulously designed waveguide – was developed in service of the principle of accurate, transparent sound.

The drivers in the Truesonic TS115 are designed to make sure that virtually no energy is wasted. That translates to more of the power from the amplifier actually working to generate sound rather than heat, giving the speaker better real world performance than other speakers with comparable published specifications. The Truesonic TS115 offers a 15" LF driver (2.5" voice coil) and a 1" HF driver (Neodyminum Driver).

You can never be too safe around the stage. We know stuff happens that you just can't predict. Sometimes it's the flying drumstick, a falling mic stand or worse. Every Truesonic speaker comes with a complete front grille from top to bottom that protects not only your low frequency driver, but your high frequency driver as well. With Truesonic speakers, you get extra peace of mind knowing that whatever comes at your sound system, we've got it covered, literally.

Features

Features

  • 1000 Watt peak power rating
  • 500 Watt program / 250 Watt continuous
  • 15” LF transducer with 2.5" voice coil
  • 1" neodymium HF driver
  • Dual electronic driver protection circuits
  • Lightweight, trapezoidal cabinet with handles
  • Two parallel Speakon NL4 jacks for input and thru connection
  • Use as a traditional upright loudspeaker or as floor wedge monitor
  • Stand and pole-mountable or flyable
Specification
Power System250 W continuous / 500 W Program / 1000 W Peak
Frequency Response (-10dB)48 Hz-18 KHz
Sensitivity (1w @ 1mt)97 dB SPL
Impedance8 ohms (nominal)
Maximum SPL @ 1m121 dB continuous/ 127 dB peak
Coverage ( HxV )80°/100° x 60° nominal
Transducer Low15" woofer, 2.5" voice coil
Transducer High1" neodymium driver
Passive Crossover2.15 kHz at 12 dB / oct, with HF protection
Enclosure ConstructionTrapezoidal, with floor monitor capability.
Enclosure ConstructionInjection molded, polypropylene enclosure, with perforated steel grille
Input ConnectorsTwo Parallel SPK NL-4 for Input / Thru
MountingIntegrated Std. pole-mount / two handle / two eyebolt point
Dimensions (WxLxH)26.73" (679 mm) x 16.94" (430.3 mm) x 15.16" (385 mm)
Weight29 lbs (13.15 kg)
