The American DJ UB 6H is a professional grade indoor 1/2-meter linear fixture powered by six 6-Watt HEX LEDs. Includes UC IR wireless remote and magnetic interlocking end caps to attach fixtures together.

Description

ADJ UB 6H 6-in-1 RGBWA+UV LED Linear Fixture

The ADJ UB 6H is a 22.5-inch (.5 meter) professional grade indoor linear fixture powered by six 6W-Watt HEX RGBWA+UV (6-IN-1) LEDs. Its bright chromatic 40-degree beam angle provides vibrant HEX color mixing designed for washing stages, walls and dance floors. Its rugged casing with patent pending Quick Align end locking allows for a seamless output of light with no breaks of color.

The UB 6H features built-in Color Macros (built-in preset colors), 4 DMX Channel Modes, 0-100% dimming and variable speed strobe. Plus, it offers flexible programming from its on-board 4-Button LED DMX-512 menu, or from the ADJ UC IR wireless remote and Airstream IR app.

Features
  • 22.5-inch (.5 meter) indoor Linear Bar with 6x 6W Ultra bright RGBWA+UV HEX (6-IN-1) LEDs
  • Variable RGBWA+UV color mixing offers a seemingly unlimited color palette - Great for Stage or Wall Washing!
  • 4 DMX Channel Modes: 6, 10, 12 or 18 channels
  • 6 operational modes: Auto Run, Program Mode, Sound Active, RGBWA+UV Dimmer, Static Color and DMX-512 Mode
  • 3-Section Pixel control
  • Patent Pending Quick Align (Magnetic)
  • Beam Angle: 40 degrees
  • Flicker Free operation @2200Hz
  • 4-Button DMX LED Display
  • 63 built-in Color Macros
  • LED pulse and strobe effect
  • Electronic Dimming: 0-100%
  • Includes mounting brackets to mount on a wall or set on the ground
  • Compatible with the ADJ UC IR (included) and Airstream IR App
  • Long Life LEDs (Rated at approximately 50,000 hrs.)
  • Power Draw: 33W @ 120V
  • Linkable: DMX via 3-pin XLR cable; Power via IEC. Daisy-chain power (Up to 17 UB 6H fixtures max., @ 120V can be power linked)
  • With Wired Digital Communication Network
  • Multi-voltage operation: AC 100V-240V 50/60Hz
  • Dimensions (LxWxH): 22.5" x 2.5" x 3.75" (560 x 63 x 90mm)
  • Weight: 3.5 lbs / 1.58 kg
  • ETL Approved

Specifications
Dimensions (H x W x D) 3.75" (90 mm) x 22.5" (560 mm) x 2.5" (63 mm)
Weight 3.5 lbs (1.58 kg)
