ART MyMONITOR Personal Headphone Monitor Mixer (Discontinued)

Part #:
MyMONITOR
Model #:
MyMONITOR
Availability: No Longer Available
Contact us for comparable solutions.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

A performer needs to hear him/herself through headphones exclusively or mixed with the output of a mixer, CD player, tape deck, or other stereo line level source. Only the mic signal, however, should be going to the main mixer.

Description

Problem:

A performer needs to hear him/herself through headphones exclusively or mixed with the output of a mixer, CD player, tape deck, or other stereo line level source. Only the mic signal, however, should be going to the main mixer.

Solution:

Connect MyMONITOR between the mic and line source, and the mixer. The Mic and line Monitor levels can then be adjusted for mix and volume through the headphones. Only the mic signal will go to the board. And since MyMONITOR can be AC or battery powered, the unit can be used on a large stage or wherever there is no AC outlet nearby. Dynamic or condenser mics can be used since phantom power would come through the Mic Thru jack from the mixer or other source.

Features

  • XLR Mic In connector accepts a dynamic or condenser mic
  • XLR Mic Thru connector for connecting MyMONITOR to the mixer's mic input
  • 1/4" stereo Monitor In jack accepts the stereo output of a mixer
  • Mic Level control regulates the mic’s headphone level
  • Monitor Level control regulates the stereo Monitor inputs level through the headphones
  • Dual stereo headphone outputs

Specifications

Signal To Noise Ratio 90dB
Gain 15dB (1/4"), 50dB (XLR)
Maximum Input Level -20dB mic, 40dB Monitor
Output Impedance 10 ohms
Power Requirements 12V DC (Adapter included) or one 9V battery
Power LED indicator
Dimensions (H x W x D) 1.5" (40 mm) x 4.5" (112 mm) x 2.75" (72 mm)
Weight 1.3 lbs (0.45 kg)
