The Ashly FR-8 8-channel network remote fader with DSP capabilities is a great choice for facilities that use amateur operators for occasional live performances. Mix and match network remotes in a single installation via a standard Cat-5 cable.
The FR-8 controls up-to eight user assigned inputs, outputs, or mixer outputs, and the FR-16 controls up-to 16. Both models are powered using Class-1 IEEE 802.3af Power over Ethernet (PoE), or by an external PoE injector when PoE is unavailable. Ethernet communication with this device is made by wiring it with standard Cat-5 cable terminated with an RJ-45 connector through an Ethernet network router, switch, hub, or patch panel to a Windows™ PC running our Protea™ ne Software v5.10 or higher. Each connect to Ethernet using a standard RJ-45, as well as Neutrik’s etherCON™ heavy duty RJ-45 and will automatically assign their IP address.
Each slider can be programmed to allow the amount of volume control you deem appropriate for the amateur operator. The LED button at the top of each slider can be programmed as a "Mute" or A/B Source select. The FR-8 will mount to a standard 4-gang US electrical wall box, and the FR-16 will mount to a modular 7-gang US wall box. Alternately, the units can be mounted to a flat surface with a cutout, or can be used as a freestanding desktop device. On the rear panel, a Euroblock contact closure can be connected to a keyed switch to lockout all front panel controls, preventing any unwanted changes
