Ashly Audio MQX-2310 Dual Channel 31 Band Graphic Equalizer (Discontinued)

Name: Ashly Audio MQX-2310 Dual Channel 31 Band Graphic Equalizer (Discontinued)
Brand: Ashly Audio
SKU: ASHLY-MQX-2310
Price: 399 USD
Availability: OutOfStock

Write a Review

Part #:

MQX-2310

Model #:

MQX-2310

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Ashly Audio MQX-2310 features two channels of 1/3 octave EQ and uses the same precision filter design and summing circuitry as the GQX Series, with true constant "Q" response.

Description

The MQX- 2310 uses the same precision filter design and summing circuitry as the GQX Series, with each filter exhibiting true Constant "Q" response. The center-detented position of each fader acts as an on/off switch for its filter, ensuring absolutely flat response and high signal to-noise ratios. A full 25mm throw makes use of every last bit of panel space so that small panel size doesn't compromise resolution.

The additional range and incredible accuracy of this fader allows for +15 dB of amplitude adjustment on each individual filter. The MQX-2310 features 2-channels of 1/3 octave EQ.

Features

Ashly Differentiator: +15/-15dB in 25 mm Fader
25 mm, detented metal shaft faders
Switchable 40Hz, 18dB/octave hi-pass filter
Tight tolerance components for precise ≤3% filter accuracy
Precision Wein-Bridge filters
Constant "Q" design
Switchable boost/cut Range of ±6 or ±15 dB
Signal and Clip LED
Balanced inputs
Servo-balanced outputs
XLR, TRS and Euroblock connections
Universal 100–240VAC internal power supply
Rider-friendly
Safety/Compliance: cTUVus, CE, FCC, RoHS

Specifications

Input Type	Active Balanced
Impedance	20KW Balanced
Max. Level	+23dBu
Connectors	1/4" Phone Jack, XLR & Barrier Strip
Output Type	Pseudo-Balanced
Impedance	200 Ohms Balanced 100 Ohms Unbalanced
Max Level	+23dBu
Connectors	1/4" Phone Jack, XLR & Barrier Strip
Frequency Response	±.25dB 20Hz-20kHz
THD (20Hz-20KHz)
IM Distortion (SMPTE)
Output Noise (20Hz-20KHz)
Crosstalk (20Hz-20KHz)
Gain Control (EQ in, all faders flat)	-¥ to +6dB
Filter Type	Constant Q/Wein Bridge
Number	2 x 31
Bandwidth	1/3 octave
Tolerance	±3%
Range	±6 or ±15dB
Subsonic Filter	18dB/octave @ 40Hz
AC Voltage Requirements	95 - 125VAC, 50 - 60Hz
Power Consumption	13W
Dimensions (H x W x D)	3.5" (89 mm) x 19" (483 mm) x 8" (203 mm)
Net Weight	10 lbs (4.54 kg)
Shipping Weight	13 lbs (6 kg)
