The nX models are designed to meet the most demanding live sound and fixed installation sound systems in stadiums, arenas, performance venues, worship spaces and convention centers.
The Ashly nX4002 is a 2 channel multi-mode amplifier capable of driving 2 Ohm loads at full power. The maximum rated output power is 400W per channel at Low Z, 70V, and 100V mode. There is an automatic but defeatable sleep mode consuming <1W. A switch mode power supply shall auto-detect 110 – 120VAC or 220 – 240VAC mains, and a Neutrik® powerCON shall be used for the AC cord. Each channel has selectable output modes of Low Z, 70V, or 100V, an 80Hz high-pass filter, input limiter, and input gain settings of 26dB, 32dB, 38dB, or 1.4V.
Each channel has a remote DC level control. Input connectors are Neutrik® XLR/TRS combo jacks and Euroblock, while output connectors are Neutrik® speakON. The unit has a front panel power switch and level controls that can be disabled. LEDs indicate Protect, Sleep, Disabled, and Bridge mode status, as well as Temperature, Output Current, Output Signal, and Clipping/Mute status per channel. The amplifier has temperature dependent variable speed forced-air cooling. The unit weighs <21.5 lbs (9.75 kg), measures 19"W x 3.5"H x 16.8"D (483 mm x 89 mm x 428 mm), and mounts in a standard 19" rack.
| Channels | 2 |
|---|---|
| Max Output Power | Measured in Watts, Per Channel, Low-Z Output, All Channels Driven |
| 2 Ohms | 400 |
| 4 Ohms | 400 |
| 8 Ohms | 400 |
| Low Z Output | Measured in Watts, Bridge Mode, All Channels Driven |
| 4 Ohms | 800 |
| 8 Ohms | 800 |
| 70V, 100V Output | Measured in Watts, All Channels Driven |
| 70V (per channel) | 400 |
| 100V (per channel) | 400 |
| Total Power Draw | Measured in Watts, Total for all Channels |
| Sleep Mode | < 1 |
| Standby Mode | 25 |
| Idle (no signal) | 40 |
| Current Draw | Measured in Amps, Total for all Channels, 120VAC, Divide by 2 for 240V |
| Sleep Mode | 0.1 |
| Standby Mode | 0.38 |
| Idle (no signal) | 0.70 |
| Max Current Draw | Measured in Amps, Typical Input, All Channels Driven, Divide by 2 for 240V |
| 1/8 Max Power @ 2 Ohms | 4.6 |
| Thermal Dissipation | BTU/hr, Typical Input, Total for all Channels |
| Sleep Mode | < 3.4 |
| Standby Mode | 85 |
| Idle (no signal) | 136 |
| 1/8 Max Power @ 2 Ohms | 305 |
| Voltage Gain | Selectable at 26dB, 32dB, 38dB, or 1.4V |
| Damping Factor | >250 (8 Ohms load |
| Input High Pass Filter | 80Hz 2nd order |
| Distortion (SMPTE, typical) | |
| Distortion (THD-N, typical) | |
| Channel Separation | -75dB (dB from full output, 1kHz) |
| Signal to Noise (20Hz–20kHz, unweighted) | >105dB |
| Frequency Response | 20Hz–20kHz, +/-0.05dB |
| Balanced Input Connector | Euroblock 3.5 mm, 1/4" TRS and XLR Combo jack |
| Input Impedance | 10k Ohms |
| Maximum Input Level | +21dBu |
| Speaker Output Connector | Neutrik® speakON |
| Remote DC Level Control | Euroblock 3.5mm - Gnd, CV, V+ per input |
| Attenuators (per channel) | Front panel and remote. Fully off = Mute |
| Amplifier Protection | Inrush current limitation, temperature monitoring, output over-power protection, mains fuses |
| Cooling | Continuously variable temperature controlled axial fan(s) |
| Environmental | 32–113 deg F, (0–45 deg, C) (non-condensing) |
| Nominal (Automatic Sensing SMPS) | 120VAC, 240VAC |
| Operating Range | 70–135VAC, 140–270VAC |
| Minimum Power-Up | 85VAC, 170VAC |
| Weights and Dimensions | |
| Dimensions (H x W x D) | 3.5" (89 mm) x 19" (483 mm) x 16.84" (428 mm) |
| Shipping Dimensions (H x W x D) | 22" (559 mm) x 24.5" (622 mm) x 5.25" (133 mm) |
| Net Weight | 25.2 lbs (11.4 kg) |
| Shipping Weight | 31.3 lbs (14.2 kg) |
