Atlas Sound AH66-12T-BSG 12" Stadium Horn (Discontinued)

Name: Atlas Sound AH66-12T-BSG 12" Stadium Horn (Discontinued)
Brand: AtlasIED
SKU: ATLAS-AH66-12T-BSG
Price: 1469.99 USD
Availability: OutOfStock

Write a Review

Part #:

AH66-12T-BSG

Model #:

AH66-12T-BSG

Current Stock:

Availability: No Longer Available

Contact us for comparable solutions.

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

The Atlas Sound AH66-12T-BSG 12 inch Stadium Horn is ideal for directional sound distribution where full range reproduction, maximum intelligibility and high sound pressure levels are required. Applications include football stadiums, sports arenas, baseball fields, convention centers and auditoriums.

Weather resistant construction features of the AH66-12T-BSG include a multiple screen configuration to prevent moisture from damaging internal components, a perforated aluminum screen covers the large horn mouth, a secondary screen is in place forward of the high frequency driver and a third tightly perforated screen protects the 12" cast frame woofer. A "weep" hole is also included on the back of the large horn "bell" to allow evaporation of any condensation that might build up internally.

Features

3 Forged Eyebolts Also Included for Suspended Installation
200 Watts Power Handling
Constant Directivity Design Offers Controlled Coverage of 65° Horizontal by 65° Vertical (2kHz Octave Band)
Driver Compliment Includes 12" Cast Frame Woofer with a Concentrically Mounted 1" Exit Compression Driver
Easy, Weather Resistant Connection via a Convenient Recessed Terminal Block Located on the Bottom of the Loudspeaker
Efficiency Rating of 102dB (1W/1m)
Heavy Duty Mounting Bracket (Included) Allows for Easy Installation to Most Any Flat Surface
Includes a Built-In, High Efficiency 60 Watt 70.7V Transformer
Maximum Output of 125dB (Rated Power @ 1M)
Neutral Battleship Gray Finish

Specifications

Power Taps	7.5, 15, 30, and 60 Watts & 8Ω
Frequency Response	80Hz - 15kHz
Driver Type	1" HF and 12" LF
Dispersion	65° x 65°
Sensitivity	102dB SPL
Dimensions (H x W x D)	23.88" (606.55 mm) x 21.41" (543.81 mm) x 22.57" (573.28mm)
Weight	82 lbs (37.2 kg)
