AtlasIED CP700 High Performance Power Amplifier Dual Channel 700W 25V, 70.7V, 100V 2,4, and 8 Ohm Outputs

Part #:
CP700
Model #:
CP700
Availability: Usually arrives in 5-9 business days. Please be aware that global supply shortages outside our control may interfere with our normal delivery times and product availability. For more information, email sales@proacoustics.com or call us at 888-256-4112.
Certified Audio
Expertise
FREE Custom
System Design
Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Get a Quote, Price or Support Fast!

We want to make contacting us as fast and as easy as possible. Please reach out if you have any questions or concerns about our products, system design, technical support, or orders.
Phone Monday - Friday
8:00 AM - 5:00 PM
1-888-256-4112
Email Contact us by email or
our simple form.
SEND EMAIL

The Atlas Sound CP700 High Performance Power Amplifier is a professional grade audio power amplifier specifically designed for demanding contractor applications, the CP700 features esoteric grade toroidal power supply and output transformers.

Description

Atlas Sound CP700 Commercial Duty Dual Channel 700 Watt Power Amplifier

The CP700's two independent channels ensure maximum channel separation and ultra-low distortion figures while providing years of faithful service.

The Atlas Sound CP700 is a professional grade audio power amplifier specifically designed for demanding contractor applications, the CP700 features esoteric grade toroidal power supply and output transformers. These transformers were chosen for their outstanding reliability as well as extended frequency response (-3dB at 30Hz - 70.7V output through the transformer).

Now you can have the peace of mind that systems specified with the CP700 will have true transformer output isolation, a feature that previously may have not been affordable due to the cost of quality external transformers. Whether your application is a large distributed constant voltage sound system or a high SPL sound reinforcement system, the Atlas Sound CP700 is the perfect answer for high power/low-cost amplification needs.

The Atlas Sound CP700 is the perfect choice for distributed paging/BGM systems, foreground music systems, and distributed sound masking applications. Also perfect for night clubs, theaters, portable sound systems, and anywhere clean high-fidelity audio amplification is needed.

Features

  • 25V, 70.7V, 100V, and Direct Coupled (2,4, and 8 Ohm) Outputs Mounted on Barrier Strips with Covers for Safety
  • Balanced Inputs on Barrier Strip and XLR Connectors
  • Dual-Speed, High Efficiency Fan Cooling
  • Loop Through Feature on Male XLRs, One per Channel Input
  • Power-Up Muting
  • Short-Circuit, Temperature, and DC Offset Protection
  • Soft Clip Limiter Protection
  • Stepped Attenuators Mounted on the Rear for Security
  • Stereo, Bridge, or Parallel Operating Modes Selectable via Rear Mounted Switch
  • Toroidal Output Transformers Provide Full Electrical Isolation and Meet Worldwide Safety Agency Approval

Specifications

25 Volts 280W X 2
70 Volts 350W X 2
100 Volts 350W X 2
140 Volts Bridged 700W
200 Volts Bridged 700W
Max Average Power @ 35Hz-20kHz 0.1% THD (10-80kHz Filter)
Inputs Balanced/Unbalanced
8 Ohms, 1kHz, 0.1% THD 240W X 2
4 Ohms, 1kHz, 0.1% THD 400W X 2
2 Ohms, 1kHz, 0.1% THD 550W X 2
Bridged Mono 8 Ohms 850W (1kHz, 1% THD)
Bridged Mono 4 Ohms 1100W (1kHz, 1% THD)
Dimensions (H x W x D) 5.19" (480 mm) x 18.9" (32 mm) x 16.85" (428 mm)
Weight 54 lbs (24.3 kg)
Shipping Weight 57 lbs (26 kg)
