Atlas Sound MUSICAVC-50Z Stereo Volume Control (Discontinued)

The MUSICAVC-50Z volume control provides clear, distortion free stereo music reproduction when one or multiple loudspeaker pairs are powered by a single amplifier. MUSICAVC-50Z is an 8Ω device with a decora-style wall plate to match virtually any decor.

Frequency response is 20Hz - 20kHz (-3dB, -0). Attenuation is accomplished in eleven steps plus positive off. The first six steps are 3dB for fine tune control at low listening levels, the next three steps are 6dB, followed by one 9dB step and finally one 28dB step before “off”.

The control knob measures 1.25” DIA. and projects a mere 11/16” for unobtrusive yet functional operation. Assemblies measure 2.69” deep and mount into a standard 20 cu. in E.O. Box (by others). Each volume control is supplied with the plate, knob, and trim piece.

• Provides Precision Level Control in 3dB Increments (Lowest 6 Steps)
• 50W Impedance Matching Volume Control
• 50 Watt Rating Achieves Clear, Stereo Music Reproduction in 8 Ohm Applications
• Impedance-Matching Capability of 2X, 4X and 8X Provides Flexibility in System Design
• Low Profile Design
• Low Profile Styling is a Favorite of Architects and Designers
• 1X Setting Allows Use as a Standard 8 Ohm Non-Impedance Matching Volume Control
• Decora-Style Plate
