The Atlas Sound TSD-DCPD DC Power Distribution is designed to distribute power to TSD devices or other equipment requiring DC power without the need for separate power supplies. One 9-24V PSU input is distributed to 6 independent, isolated outputs.

Description

The Atlas Sound TSD-DCPDV is designed to distribute power to TSD devices or other equipment requiring DC power without the need for separate power supplies. One 9-24V PSU input is distributed to 6 independent, isolated outputs.The compact TSD-DCPD will help remove rack clutter and free up power strip space.

Unit requires Power Supply that is sold separately for proper function, multiple TSDs can be powered with one power supply based on current requirements. This unit has a power requirement of 20mA but the power requirements of attached TSDs must be accounted for when selecting the proper power supply. For multiple TSD applications use the TSD Power Calculator to determine the proper power supply needed.

Features

Power Distribution for Up to 6 TSDs From a Single PSU
1 in 6 Out ConfigurationSix (6) Independent 9-24V Outputs
DC Filtering and Isolation Per Channel
9 - 24VDC Input Voltage (Power Supply Current Selection is Dependent on the Number of Devices Connected to the DCPD and Their Accumulative Current Consumption)
Energy Efficient

Specifications

DC Voltage Input	9V - 24V DC, 5A Max
Outputs Voltage	9V - 24V DC, Dependent on the DC Input Votage
Output Current	Voltage and Current Related to Input Power Supply
Dimensions (H x W x D)	1.5" (3.81 cm) x 4" (10.16 cm) x 2.5" (6.35 cm)
Weight	6 oz (.165 kg)
