| Receiving System | Non-diversity, single-channel, dual antenna system |
|---|---|
| Image Rejection | 50 dB minimum |
| RF Sensitivity | 20 dBuV at 60 dB S/N ratio (50 ohms termination) |
| Audio Output | 1/4" (6.3 mm), unbalanced: 700 mV (1 kHz modulation, 10 kHz deviation, 100k ohm load), nominal |
| Power Supply | 100-240V AC (50/60 Hz) to 12V DC .5A (center positive) switched mode external power supply |
| Dimensions (Receiver) | 7.48" (190.0 mm) W x 1.82" (46.2 mm) H x 5.06" (128.5 mm) D |
| Net Weight (Receiver) | 11.8 oz (335 grams) |
| RF Power Output | 10 mW |
| Spurious Emissions | Following federal and national regulations |
| Batteries | Two 1.5V AA Alkaline (not included) |
| Battery Life | 8 hours (alkaline)Depending on battery type and use pattern |
| Dimensions (Handheld Transmitter) | 9.91" (251.8 mm) long,2.11" (53.5 mm) diameter |
| Net Weight | 9.2 oz (260 grams)(without battery) |
| Accessory Included | AT8456a Quiet-Flex™ stand clamp |
