Designed to work with phantom-powered, condenser gooseneck microphones with a 3-pin XLRM-type output, the ATW-T1007 System 10 Microphone Desk Stand Transmitter pairs with the System 10 or System 10 PRO digital wireless receiver of your choice to provide rock-solid, 2.4 GHz wireless performance. The transmitter is equipped with a 3-pin XLRF-type input, and features a touch-sensitive user switch that can toggle between talk and mute modes, or function as a press-to-talk or press-to-mute button. Two red/green LEDs – one visible from the front of the unit, the other from the rear – indicate toggle/talk/mute mode, battery level, and charging status.
The ATW-T1007 also offers three levels of input gain (-6 dB, 0 dB and +6 dB), which can be selected via a switch on the bottom of the unit. Another switch engages the low-cut filter. The 3.7V rechargeable lithium-ion battery provides nine hours of use on a full charge and is easily recharged with the included USB charging cable.
| Operating Frequencies | 2.4 GHz ISM band |
|---|---|
| Total Harmonic Distortion | |
| Operating Temperature Range | 0° C to +40° C (32° F to 104° F) |
| Charging Temperature Range | 5˚C to + 35˚C |
| Frequency Response | 20 Hz to 20 kHz |
| Audio Sampling | 24 bit / 48 kHz |
| RF Power Output | 10 mW |
| Spurious Emissions | Following federal and national regulations |
| Power Supply | 100-240V AC (50/60 Hz) to 5V DC 0.5A switched mode external USB-type power supply |
| Internal Battery | 3.7 V Rechargeable Li-ion Battery |
| Battery Life | 9 hours |
| Battery Charging Time | 4 hours 30 minutes |
| Accessory Included | AC adapter (USB-type), USB cable |
| Dimensions (H x W x D) | 1.74" (44.2 mm) x 3.78" (96.1 mmm) x 4.83" (122.8 mm) |
| Weight | 0.86 lbs (0.39 kg) |
