Biamp Desono ENT-FRW 3-Way White Column Line Source Loudspeaker

The Desono ENT-FRW is a high-performance, three-way column line source loudspeaker, available in white, engineered for permanent installation in acoustically challenging environments. Its architecturally refined enclosures and modular scalability support configurations ranging from a single unit to floor-to-ceiling arrays of virtually any length, making it ideal for auditoria, airports, train stations, conference centers, houses of worship, stadium concourses, museums, and other large spaces.

Optimized for medium to large, highly reverberant areas, the ENT-FRW functions as a true line source. Longer arrays reduce unwanted reflections, minimize reverberation, and significantly improve speech intelligibility. Its modular design allows installers to position the vertical system lobe symmetrically or asymmetrically about the column axis. Multiple ENT-FRW columns can be used to create single lobe, focused coverage, or combined with ENT-LF modules to form tall arrays with multiple vertical lobes at independent points, previously achievable only with powered, digitally steered arrays.

With all-weather construction, the ENT-FRW is suitable for both indoor and outdoor direct-exposure applications. A wide range of mounting brackets is available to accommodate nearly any installation. For optimal performance, the Community ALC1604D Amplified Loudspeaker Controller is recommended, though higher-power ALC models are also fully compatible.

Note: Formerly sold under the Community brand, this speaker continues to offer the same quality and features.

Features

Features

Zoom Certified
Modular design for versatile coverage free of unwanted lobes
Wide frequency range and high output level
Highly intelligible voice reproduction and excellent musical sound quality
Simple installation using a variety of versatile mounting accessories
Integrated T-Bar mounting bracket included with each column
Sleek white finish blends discreetly into any venue
5-year warranty

Specification

Operating Mode	Passive
Operating Environment	Indoor or outdoor direct exposure
Operating Range	200 Hz - 20 kHz
Nominal Beamwidth (H x V)	Horizontal: 120° Vertical: 12° or 6° (user configurable)
Transducers	LF: Six 3.5" neodymium MF: Eighteen 2.35" HF: Forty-two 1" (six 7" long by 1" wide planar-coupled Compact Ribbon Emulators)
Continuous Power Handling	85V, 600W @ 12Ω (2400W Peak) @ Nominal Impedance
Nominal Sensitivity	Curved (12°): 93 dB Straight (6°): 95 dB
Nominal Maximum SPL (Single unit)	Curved (12°): 120 dB Straight (6°): 122 dB
Typical SPL at 100 feet (30 meters)	96 dB
Required Accessories	Digital Signal Processor / External High Pass Filter - 200Hz, 12 dB /octave
Recommended Amplifiers	600W - 1200W @ 12Ω (85V - 120V)
Baffle Form	Configurable; straight, curved, and asymmetric curve
Input Connection	Top: (1) Dual Banana (male) Bottom: (1) NL4 locking connector (2) Terminal strip (1) Banana (female)
Environmental	IP54 per IEC 60529, designed in accordance with MIL-STD-810G. Included ABS plastic rain cover with integrated cable inlet and 1" (25.4 mm) knockout for conduit ingress
Dimensions (H x W x D)	44.5" (1129 mm) x 5.5" (140 mm) x 7.36" (187 mm)
Net Weight	40 lbs (18.1 kg)
Shipping Weight	50 lbs (22.68 kg)
