Biamp Tesira TEC-1i In-Wall PoE Ethernet Control

By Biamp Systems

Biamp Tesira TEC-1i In-Wall PoE Ethernet Control

Name: Biamp Tesira TEC-1i In-Wall PoE Ethernet Control
Brand: Biamp Systems
SKU: BIAMP-909.0318.900
Price: 818 USD
Availability: InStock

Write a Review

Part #:

920-00318-00001

Model #:

Tesira TEC-1i

Current Stock:

Availability:

Special Order (Return conditions apply)

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

The Biamp Tesira TEC-1i is an Ethernet control device for use with all Tesira systems. It offers a simple, intuitive interface for end users and can be installed and configured to fit the unique needs of a particular application.

Description

Biamp Tesira TEC-1i In-Wall Ethernet Control

The Tesira TEC-1i is an Ethernet control device for use with all Tesira systems. It offers a simple, intuitive interface for end users and can be installed and configured to fit the unique needs of a particular application. The TEC-1i connects via standard CAT-5/6/7 cabling and is powered over Ethernet, eliminating the need for custom cabling and local power sources. Multiple remote control panels can be connected over large distances using standard network technology. The TEC-1i can be flush-mounted into any wall.

Applications

Source Selection: Selection and level control of input sources for background music, such as CD player and auxiliary devices.

Paging/Music: Zone page routing and music source selection with independent page/music volume control.

Restaurant/Bar: Music source selection and room volume control, independent per zone, or in a single centralized control.

A/V Conferencing: Individual source volume control and selection of room mode presets (i.e., conferencing or video playback).

Room Combining: Remote selection of room combinations, based on preset configurations or moveable partitions, with automatic combining of volume functions.

The Tesira TEC-1i complies with the United States Trade Agreement Act (TAA), allowing it to be included in GSA Schedule contractors’ sales bids for the U.S. federal government.

Features

Adjustment and/or initiation of 32 selectable system volumes and actions
Volumes are any individual or grouped system levels, including inputs, outputs, matrix crosspoints, etc.
Actions are any individual or grouped system operations, including presets, source selection, mutes, ducking, combining, etc.
Control functions are programmed in the Tesira system design software
High contrast OLED display with a wide viewing angle
The display brightness can be adjusted to fit the ambient light present in the application and automatically dims when not in use
Capacitive touch technology eliminates protruding and moving parts to increase product reliability and longevity while simplifying cleaning
TEC-1i flush mounts to any wall; mounts using the retrofit plate (included) or installs in a Raco® 254 box for North American installations (not included)
330 feet (100m) Ethernet cable length can be extended with standard PoE network technology (routers, switches, hubs, media converters)
Connects with standard RJ-45 or IDC connector
Compliant with the US Trade Agreement Act (TAA)

Specifications

Power Consumption	PoE+ (IEEE 802.3at Class 1, 4W)
Control Cable Requirements	Unshielded twisted pair (UTP) wiring, 100 BaseT interface (CAT-5/6/7 Ethernet cable) using either RJ-45 or Insulation Displacement Connector (IDC)
Control Cable Length	330' (100 m) Ethernet cable length can be extended with standard PoE network technology
Control Wiring Topology	Standard Ethernet network wiring
Control Programming	Each control configured for specific operation by the system design software
Compliance	RoHS Directive; CE; FCC
Dimensions (H x W x D)	6.22" (158 mm) x 5.82" (148 mm) x 0.5" (12.7 mm)
Weight	0.5 lbs (0.2 kg)
