Blizzard Lighting LB BAR CSI 9x 3W UV LED Linear Wash Fixture

Home /
Blizzard Lighting LB BAR CSI 9x 3W UV LED Linear Wash Fixture (Discontinued)

Description

Details

Blizzard Lighting LB BAR CSI 9x 3W UV LED Linear Wash Fixture

9x 3-watt UV LED Bar

LB BAR™ CSI is a linear UV wash fixture with 9x 3W LEDs, and is perfect for clubs, DJs, or any indoor application. It has a 4-button LED control panel which allows control of 0-100% UV output level, 0-20Hz strobe, standard dimming plus 4 selectable 32-bit dimming curves, and it is totally silent due to its natural convection cooled design with no fans.

Fixture Alignment

LB Bar™ CSI is equipped with locking end alignment clips to allow seamless multi-fixture light output with no color breaks. It is light weight, solidly built, and also offers dual mounting brackets with locking knobs, IEC power in/out, and 3-pin DMX input/output connections.

Features

Features

9x high output 3-watt UV LEDs
Emits a wide 110° beam angle
User selectable 1 or 3 DMX channel modes
Variable electronic dimming
Strobe effects (1-20Hz)
Standalone, master/slave and DMX modes
4-button LED control panel for easy programming
End-to-end fixture locking connections
Standard plus 4x 32-bit dimming curves
Natural convection cooled, totally silent operation
3-pin male/female XLR input & output
IEC power In/Out connections

Specification

Operating Voltage	110-240VAC, 50-60 Hertz
Power Consumption	24W, .27A, PF: .65
LED	9* high output 3-watt UV LEDs
Beam Angle	110 degree beam
Wavelength	393~396nm
Max. Operating Temperature	104 degrees F (40 degrees C) ambient
Protocol	USITT DMX-512
DMX Channels	1/3-channel
Input/Output	3-pin XLR Male/Female
Other Operating Modes	DMX512, M/S, Standalone Mode
Warranty	2-year limited warranty, does not cover malfunction caused by damage to LEDs
Dimensions (H x W x D)	4.3" (109.22 mm) x 16.4" (417 mm) x 2.3" (58.42 mm)
Weight	1.7 lbs (0.75 kg)
