he Bogen Model MBS1000A is a dual-impedance, uni-directional, dynamic desktop microphone with a rubberized finish for all industrial and commercial public address and paging applications. The MBS1000A has a bottom-mounted slide switch for low- or high impedance selection. The wide band frequency response is smooth and peak free, thereby providing a natural, highly-intelligible sound.
The microphone output provides a normally open switch closure pair that can be used to operate external equipment. When the microphone is activated using either the push-to-talk or lift-to-talk functions, the provided contact closes. The push-to-talk actuator bar includes a locking feature to allow the mic to remain active for extended periods. The lift-to-talk feature can be enabled or disabled using a bottom mounted selector switch.
Four molded, non-skid, non-marring and permanently resilient "feet" are located under the cast base.
| MIC Type | Desktop |
|---|---|
| Element | Dynamic |
| Polar Pattern | Cardioid |
| Impedance | Lo-Z, 500 ohms; Hi-Z, 50k ohms(switch-selectable) |
| Frequency Response | 45 Hz to 15 kHz |
| Sensitivity | Hi-Z: -52 dB +/- 3 dB, Lo-Z: -72 dB +/- 3 dB |
| Cable | 7' of 4-conductor, 2-shielded |
| Switch | Locking push-to-talk, lift-to-talk,impedance selector |
| Material | ABS plastic |
| Finish | Rubberized black finish |
| Dimensions | 4-3/8" W x 9-3/8" H x 5-7/8" D |
| Weight | 1-1/4 lbs |
