Bosch PVA-4R24 PAVIRO Matrix Router

The PVA-4R24 24 Zone Router is a zone extension for the PAVIRO system. The PVA-4R24 adds 24 zones, 20 GPIs, 24 GPOs, and 2 control relays to the system and is controlled and supervised via the CAN bus by the PVA-4CR12 (Controller). Up to 20 external routers can be connected to one controller. One router can handle up to 4000 W speaker load. The maximum load of one zone is 500 W. The zone indicator lights on the front indicate the current status of every zone:

• Green: Zone in use for non-emergency purpose

• Red: Zone in use for emergency purpose

• Yellow: Zone fault detected

• Off: Zone in idle condition

• Routing up to 24 zones from 2 - 500W
• Low power consumption in standby mode
• Extreme flexibility
