The Bose FreeSpace DS 40SE is the most versatile member of the DS loudspeaker family. It is a high-performance, full-range, loudspeaker designed for foreground, background music, speech reproduction in a wide range of installed applications.

Description

For indoor and outdoor applications, the Bose® FreeSpace DS 40SE is the most versatile member of the DS loudspeaker family. It is a high-performance, full-range, surface mount loudspeaker designed for foreground and background music and speech reproduction in a wide range of installed applications. The DS 40SE features high output and 125° x 125° coverage pattern with a frequency range down to 70 Hz. EN 54-24 compliant DS loudspeaker models are also available for use in Voice Alarm (VA) systems.

Features
  • Full-range loudspeaker with a single 4.5" (114 mm) full-range driver in a ported enclosure designed for surface mounting in foreground and background music and paging applications
  • Simple 1->2->3 installation system. Mounting hardware allows for horizontal and vertical orientation with adjustable pitch or yaw
  • Integrated multi-tap transformer with innovative thumb wheel adjustment for easy-to-change tap settings from under front end cap
  • Shared voicing across entire FreeSpace DS product family enables DS 16, DS 40, and DS 100 loudspeakers to be integrated on the same system and maintain consistent tonal quality
  • Supported by a suite of accessories, including wall-mount bracket, ceiling-mount bracket, pole-mount bracket and junction boxes

Specifications
System Performance
Frequency Response (+/-3 dB) 80 Hz - 17 kHz
Frequency Range (-10 dB) 70 Hz - 19 kHz
Nominal Dispersion 125° H x 125° V
Recommended High-Pass Filter 70 Hz high-pass filter
Loudspeaker EQ Recommended
Overload Protection PTC/Resistor
Long-Term Power Handling 40W (160W peak)
Sensitivity (SPL / 1W @ 1 m) 87 dB SPL
Maximum SPL @ 1 m 103 dB SPL (109 dB SPL peak)
Nominal Impedance 8Ω (transformer bypassed)
Transformer Taps (70/100V) 70V: 2.5W, 5W, 10W, 20W, 40W
100V: 5W, 10W, 20W, 40W
Transducers
Driver Compliment 4.5" (114 mm) full-range driver
Physical
Enclosure PC/ABS, textured
Grille Powder-coated steel grille
Environmental Outdoor per IEC 529 IP55
Connectors Three-terminal barrier strip integrated on included mounting bracket. Optional accessories available for use when ceramic connector and thermal fuse are required. Wire gauge: 18 AWG (0.8 mm) to 14 AWG (2.0 mm)
Suspension / Mounting Included bracket allows for horizontal or vertical mounting positions, pitch or yaw adjustment. Insert on rear of enclosure sized for M4 x 14 mm screw for use with safety chain
Dimensions (H x W x D) 6.3" (159 mm) x 12.8" (326 mm) x 6.9" (175 mm)
Depth with wall mount bracket: 9.4" (238 mm)
Net Weight 8.5 lbs (3.9 kg)
Shipping Weight 10.8 lbs (4.9 kg)
