The Bose Professional sound quality you expect. The improvements you need. FreeSpace FS loudspeakers are the next step of our widely trusted line of in-ceiling and surface-mount loudspeakers, offering significant upgrades in durability, design, and ease of installation — all with remarkably consistent tonality. Engineered for high-quality performance in both background music and voice announcement applications, FS loudspeakers are ideal for almost any commercial space. The line includes five loudspeakers, two distinct levels of sound, new mounting options, and a modern aesthetic to match. For those seeking consistent, quality installed sound, FreeSpace FS loudspeakers are the perfect mix of performance and value.
Included Accessories: Each FS2P includes one (1) 4.5 meter (15 foot) gripple brand adjustable suspension cable system, four (4) cable ties, one (1) input cover and one (1) safety cable attachment.
Safety Ratings: Certification: UL 1480A, ULC-S541 for Fire Alarm and Signaling Systems
Applications:
| Frequency Response (-3 dB) | 95 – 16,000 Hz |
|---|---|
| Frequency Range (-10 dB) | 83 – 19,000 Hz |
| Nominal Coverage Angle | 140° |
| Nominal Coverage (1 - 10 kHz) | 130° |
| Power Handling, Long-Term Continuous | Bose extended-life cycle test: 16W AES transducer test: 20W |
| Power Handling, Peak | Bose extended-life cycle test: 64W AES transducer test: 80W |
| Sensitivity (SPL/1W @ 1 m) | Bose extended-life cycle test: 87 dB AES transducer test: 97 dB |
| Calculated Maximum SPL @ 1 m | Bose extended-life cycle test: 99 dB AES transducer test: 100 dB |
| Calculated Maximum SPL @ 1 m, Peak | Bose extended-life cycle test: 105 dB AES transducer test: 106 dB |
| Loudspeaker EQ | No Bose Professional EQ required when speaker used for general use. Bose Professional EQ Voicing and SmartBass available. EN54-24 equalization is required for EN54-24 use; refer to installation guide for details |
| Recommended High-Pass Protection | 85 Hz with minimum 24-dB/octave filter |
| Transformer Taps | 70V: 1, 2, 4, 8, 16W, bypass 100V: 2, 4, 8, 16W, bypass |
| Full-Range Driver | 1 x 2.25-inch woofer (57 mm) |
| Nominal Impedance | 16 ohms (transformer bypass) |
| Enclosure Material | Engineered-plastics |
| Grille | Perforated steel, powder-coated finish |
| Logo | Removable |
| Color | Black: similar to Ral 9005 |
| Environmental | Indoor only |
| Safety Agency | Certification: EN 54-24: 2008 for Voice Alarm Systems; UL 1480(A). For EN 54-24 specifications, refer to the installation guide. EN 54-24 equalization required for EN 54-24 use Installation: NFPA 70, NFPA 72, CSA C22.1 Section 32 |
| Operating Temperature Range | 0 °C to 50 °C (32 °F to 122 °F) |
| Connectors | Euroblock 6-pin connector with loop-through, mounted on top. Accepts 18 AWG (0.8 mm2) to 14 AWG (2.5 mm2) size wire. Includes input cover |
| Suspension/Mounting | Each FS2P has one (1) suspension attachment point and one (1) safety cable attachment point Included is one (1) 4.5 meter (15 foot) gripple brand adjustable suspension cable |
| Optional Accessories | Pendant Suspension Cable kit (2-pack), Ceramic Terminal and Thermal Fuse Kit (10-pack) |
| Dimensions (Enclosure Dia x D) | 5.87" (149 mm) x 7.2" (183 mm) |
| Dimensions with Suspension Tab (Enclosure Dia x D) | 5.87" (149 mm) x 8.46" (215 mm) |
| Net Weight | 3.25 lbs (1.47 kg) |
| Shipping Weight (Pair) | 8.95 lbs (4.06 kg) |
Usually arrives in 5-9 business days.
