The Bose® LT 9403 is a full-range 3-way loudspeaker designed as the primary reinforcement source for smaller venues, or for use with other LT loudspeakers to form Coherent Zone arrays in medium to large venues. The large-format waveguide and 90° x 40° pattern deliver precise coverage and high intelligibility, providing a cost-effective alternative to multiple-cabinet line arrays for many applications.
Applications:
Bose® LT Series loudspeakers are comprised of 6 mid/high-frequency loudspeakers, 2 full-range loudspeakers and 2 low-frequency subwoofers, all designed for permanently installed sound systems that provide precise coverage pattern control, with high intelligibility and excellent tonal balance for music sources. The flexible product line provides scalable solutions appropriate for venues ranging from small 300-seat auditoriums to large stadiums and arenas. The classic point-source design approach of Bose LT Series loudspeakers provide an effective alternative to multiple-cabinet line arrays for many venues, often providing more uniform coverage for complex seating area geometries.
All Bose LT Series mid/high-frequency and full-range loudspeakers feature the Bose V2 Midrange Manifold. This proprietary Bose technology combines the output of two (2) 4.5-inch extended-range cone drivers in a combination heat-sink/acoustic summation manifold, to significantly lower cone breakup distortion and improve transient response as compared to single 8" to 12" woofer designs. The result is a smoother, more natural vocal range response.
| Frequency Response | 50 Hz - 16 kHz (+/-3 dB) |
|---|---|
| Frequency Range | 42 Hz - 18 kHz (-10 dB) |
| Nominal Dispersion | 90° H x 40° V |
| Sensitivity | 95 dB SPL (SPL / 1 W @ 1 m) |
| Maximum SPL @ 1 m | 122 dB SPL (133 dB SPL peak) |
| Crossover Type | Passive, Bi-Amp, Switchable |
| Crossover Frequency | 300 Hz and 1.8 kHz passive, 300 Hz bi-amp |
| Recommended High-Pass Filter | 40 Hz with 4th order filter (24 dB / octave) |
| Driver Compliment | HF: 1.75" (44 mm) voice coil compression driver MF: Bose V2 midrange manifold with 2 x 4.5" (114 mm) cone drivers LF: 15" (381 mm) woofer with 4" (102 mm) voice coil |
| Enclosure | Baltic birch plywood, 13-ply, 18 mm |
| Finish | Polyurethane-based textured paint, black or white |
| Grille | 16-gauge perforated steel grille with powder-coated finish |
| Environmental | Indoor use only |
| Connectors | Two (2) parallel-wired NL4 Neutrik® Speakon® connectors |
| Suspension/Mounting | Sixteen (16) points SAE 3/8" - 16 threaded inserts (4 each: top, bottom, sides), steel |
| Dimensions (H x W x D) | 34.4" (873 mm) x 24.1" (612 mm) x 22.6" (575 mm) |
| Net Weight | 142 lbs (64.4 kg) |
| Shipping Weight | 165 lbs (74.5 kg) |
