Bose Professional ShowMatch SM20 Modular Array Loudspeaker

Bose Professional ShowMatch SM20 Modular Array Loudspeaker

Name: Bose Professional ShowMatch SM20 Modular Array Loudspeaker
Brand: Bose Professional
SKU: BOSE-730999-8860
Price: 4999 USD
Availability: InStock

Write a Review

Part #:

730999-8860

Model #:

SM20

Current Stock:

Availability: 6 - 8 Week Lead Time

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

Description

Bose Professional ShowMatch™ DeltaQ™ SM20 full-range array modules provide 20° nominal vertical coverage with included field-changeable waveguides offering choice of 70° or 100° horizontal coverage and optional accessory 120° waveguides. Replace single waveguide panel to form horizontal asymmetrical patterns. The 2-way module requires external power amplifiers (2- channels) and DSP to provide full-range response from 59 – 17,000 Hz with peak array output of up to 145 dB.

Features

DeltaQ™ technology is the next-generation line-array design that allows “Q” (directivity) to vary with each module in the array for more consistent coverage over wide frequency range, reduced array weight and cost, and outstanding vocal clarity. Arrays can cover large vertical angles with fewer boxes.
Changeable waveguides –includes both 70°and 100°waveguides to adjust horizontal coverage. Largest-in-class size provides superior coverage control and vocal clarity. Change single panel for asymmetrical patterns. Optional 120°waveguides for SM20.
Compact, portable enclosure –Versatile design allows both fixed install and portable applications, from small clubs and houses of worship to the largest performing arts centers and AV productions.
Tour-sound output level –4x Bose EMB2S compression drivers, improved with more HF output, and 2x 8-inch neodymium high-power woofers allow array output up to 145 dB SPL.
3-point “quick pin” rigging -Fast, easy setup with up to 24 full-range modules and 10:1 safety factor.
Removable side rigging -guard/handles –provides rigging guard and hand modules and 10:1 safety factor.holds for portable applications. Easily removed for permanent installs for reduced width and cleaner visual appearance.

Specifications

Frequency Response (+/-3 dB)	69 Hz - 17 kHz
Frequency Range (-10 dB)	59 Hz - 17 kHz
Sensitivity (SPL / 1 W @ 1 m)	Low Frequency: 94 dB High Frequency: 104 dB
Maximum SPL @ 1 m	Low Frequency: 121 dB High Frequency: 124 dB
Nominal Coverage Pattern (H x V)	100° H x 20° V (includes waveguides for 70° H x 20° V)
Long-Term Power Handling	Low Frequency: 450W (1800W peak) High Frequency: 100W (400W peak)
Calculated Maximum SPL @ 1 m, peak	Low Frequency: 127 dB High Frequency: 130 dB
Nominal Impedance	Low Frequency: 8Ω High Frequency: 6Ω
