- Description
Details
This amplifier has been designed to mount under a desk, in a podium, or to nearly any flat surface with the ability to control the volume from a decora style wall plate. This simple discreet solution provides sound reinforcement from a concealable amplifier capable of filling a classroom, meeting room, huddle space, or workshop with rich sound while offering a convenient remote control that can be installed within reach.
In a crowded room a speakers voice can quickly be lost to the noise. Ensure that every word can be heard with this simple audio reinforcement amplifier. Each word will be launched at the audience with 15 watts of power at 4Ω resistance providing distinct audio to all listeners.
There is no need to search for controls or fiddle with settings when preparing to present. The remote control wall plate can be installed in the location that is most convenient to a presenter, ensuring a smooth start to any meeting.
Dynamic presentations may require more than dazzling vocals to deliver the intended message. This amplifier incorporates a 3/4 inch microphone port and a 3.5mm stereo audio line level input, offering the ability to deliver reinforced content from an audio source such as a laptop or a triumphant oration leaving the audience astounded.
This amplifier simplifies audio reinforcement installation. No brackets or field terminations are required with this amplifier. Simply secure the amplifier with the built-in mounting brackets to the desired location, attach speaker wires, and plug in a cat5e or cat6 cable to connect the remote control wall plate.
- Features
Features
- 15 watts (RMS) per channel
- Remote wired wall plate controller
- 1/4" dynamic microphone and 3.5mm stereo audio line level inputs
- Built in mounting bracket
- Specification
General Output Power 15W (RMS) Per Channel (@ RL = 4Ω) Total Harmonic Distortion 0.06% (at RL = 8Ω, F = 4Ω) Minimum Load Resistance 4Ω Chipset (ST LM833DT, (TI) TPA3110D2PWPR Microphone Pre-Amplifier Gain 40dB Power Source 12V / 2A Approvals RoHS2, FCC Operating Temperature 0° to +50°C / 20-80% RH (Non-Condensing) Storage Temperature -20°to +70°C / 10-90% RH (Non-Condensing) Amplifier Amplifier Type Class D Inputs Dynamic Microphone or Stereo Audio Line Level Material Housing Steel Amplifier Dimensions (H x W x D) 1.22" (31 mm) x 4.49" (113.5 mm) x 3.84" (97.6 mm) Volume Control Material ABS Wall Plate Dimensions (H x W x D) 4.49" (114 mm) x 2.74" (69.5 mm) x .26" (6.5 mm) Volume Control Dimensions (H x W x D) 4.06" (103 mm) x 1.30" (33.1 mm) x 1.95" (49.6 mm) - Documents
Documents
- In The Box
In The Box
- (1) Compact Amplifier
- (1) Decorator Volume Control Wall Plate
- (1) Face Plate Cover
- (1) Power Adapter
- (2) Bracket Mounting Screws 6-32 (25mm)
- (3) Wall Plate Mounting Screw M3.5 (8mm)
- User Manual
