CAD Audio STAGE7 7-Piece Drum Microphone Pack

Name: CAD Audio STAGE7 7-Piece Drum Microphone Pack
Brand: CAD Audio
SKU: AST-STAGE7
Price: 199.99 USD
Availability: InStock

Write a Review

Part #:

STAGE7

Model #:

STAGE7

Current Stock:

Availability: Usually arrives in 5-9 business days.

Quantity:

Certified Audio
Expertise

FREE Custom
System Design

Get Expert
Help Fast

Ask an Expert

Our expertly trained Sales Engineers are ready to help!

(888) 256-4112

7-Piece Drum Microphone Pack - Three D29, Two C9, One D19, One D10

Description

Includes three D29 dynamic tom mics, one D19 dynamic snare mic, both with integrated drum clips, one D10 dynamic kick drum mic with clip, and two C9 overhead condensers with clips. Protective carrying case included.

Specifications

C9 Cardioid Condenser Instrument Mic
Operating Principle	Condenser
Polar Pattern	Cardioid
Frequency Response	40Hz -13KHz
Sensitivity	(2.2mV) @ 1 Pa
Impedance	150 Ohms
Max SPL	140dB
Self Noise	27dBA
Power Requirements	P12, P24, P48, 2.2mA
RF Immunity	Meets or Exceeds EN55103-2, E1-E4
RoHS	Compliant
Weight	0.07 lbs (0.032 kg)
D29 Cardioid Dynamic Percussion Mic
Operating Principle	Moving-Coil Dynamic
Polar Pattern	Cardioid
Frequency Response	90Hz -13KHz
Sensitivity	-53dBV (2.2mV) @ 1 Pa 90
Impedance	560 Ohms
RF Immunity	Meets or Exceeds
RoHS	Compliant
Weight	0.406 lbs (0.19 kg)
D19 Supercardioid Dynamic Percussion Mic
Operating Principle	Moving-Coil Dynamic
Polar Pattern	Supercardioid
Frequency Response	90Hz -14KHz, -6dB
Sensitivity	-56dBV (1.6mV) @ 1 Pa 9
Impedance	300 Ohms
RF Immunity	Meets or Exceeds
RoHS	Compliant
Weight	0.406 lbs (0.19 kg)
D10 Cardioid Dynamic Kick Drum Mic
Operating Principle	Moving-Coil Dynamic
Polar Pattern	Cardioid
Frequency Response	50Hz -16KHz
Sensitivity	67dBV (0.45mV) @ 1 Pa 90
Impedance	60 Ohms
RF Immunity	Meets or Exceeds
RoHS	Compliant
Weight	0.797" (0.36 kg)
