Califone WS-CK1 PA Wireless Upgrade Package (Discontinued)

Description

Details

Califone WS-CK1 Wireless Upgrade Package

When school budgets are tight, oftentimes institutions don't update or upgrade costly PA gear they've already invested in.

With our cost-effective WS-CK1 Wireless Upgrade Kit, you can instantly and quickly turn your existing wired PA into a wireless PA to enhance its performance or modernize any outdated 700MHz speaker. Converting to a wireless PA can bring forth several benefits to enable educators and students to project audio, make announcements or play music during sporting events, meetings, class presentations, and other indoor/outdoor situations with more flexibility.

The WS-CK1 enables wireless transmission to a wired PA from anchored audio sources such as computers and MP3 players. The WS-T transmitter included in the kit has an adjustable range up to 300' within line of sight, a 3.5mm mic input where the included HBM319 headset can be connected and can be either worn on the hip or around the neck with an available lanyard. To upgrade your existing wired PA, simply connect the included headset mic to the transmitter and then match one of the 16 frequency channels on the transmitter to the same one used on the included WS-R wireless receiver. The final step is to connect the receiver to the "aux" or "line in" on your existing PA (connecting cable is not included). The kit also includes two WS-CR charging cradles (with power adapters) and is available in the PA419WS iPod Wireless Portable PA System package.

Features

Features

HBM-319 headset
WS-T wireless transmitter
WS-R wireless receiver
Two WS-CR charging cradles (power adapter included)

Specification

Operational Range	Low TX Power / Low RX Sens.: > 100' Low TX Power / High RX Sens.: > 200' High TX Power / Low RX Sens.: > 200' High TX Power / High RX Sens.: > 300' Line-of-sight required. Range may be lower due to obstructions / interference
Frequency Response	100 Hz - 8 kHz +/- 3dB (Mic/Line Inputs)
THD + N%	< 3 % (Mic/Line Inputs)
Channels	16 (Transmitter Channels) 1 Mono (Transmit Channels)
Frequency Range	902 - 928 MHz
Power Requirements	Uses 3.7 V / 1800 mAh Li-Ion battery
Output Power	Low: 5 mW / High: 10 mW
Sensitivity	50 mV (Mic Input) 250 mV (Line Input)
Battery Usage Time	> Receiver 11 hours, Transmitter 7 hours
Battery Recharge Time	< 13 hours for the Transmitter & Receiver
S/N Ratio	> 60 dB
Warranty	For use in school, business, church and government facilities for 1 year
Dimensions (H x W x D)	21.5" (546 mm) x 15.5" (394 mm) x 9.25" (235 mm)
Net Weight	2 lbs (0.9 kg)
Shipping Weight	4 lbs (1.8 kg)
