The ultimate all-in-one power conditioner, the Carvin AC120S provides ten outlets that sequentially power on and protect your gear on any stage. Much more than a surge suppressor, this unit is equipped with an EMI/ RFI line filter to provide you a hum-free show, while adjustable LED rack lighting helps you set up in the darkest venues.

Description

Carvin AC120S All-in-One Power Conditioner/Sequencer

The ultimate all-in-one power conditioner, the AC120S provides ten outlets that sequentially power on and protect your gear on any stage. Much more than a surge suppressor, this unit is equipped with an EMI/ RFI line filter to provide you a hum-free show, while adjustable LED rack lighting helps you set up in the darkest venues.

Sequential Power On/Off

Turning on (or off) a complete audio system from one switch can create loud "pops" which can damage speakers and other gear.

The AC120S features sequenced power start-up and shutdown. Each outlet is turned on one at a time, with a delay between each one.

Power and RF Protection

Ten protected outlets feature both surge protection and RF filtering to provide stable noise-free power to your equipment.

See in Dark Places

Two extendable light tubes bring LED lighting to your rack so you can access gear quickly once the venue lights go dark.

Features

  • Total Current Rating: 20 Amps
  • Outlet Rating: 15 Amps
  • Total Number of Outlets: 10
  • Grounding: 3 Pin Grounded to AC Input Ground
  • Operating Voltage: 90-130 VAC
  • AC Cord Length: 68"
  • AC Digital Volt Meter: 3 Digit, 0 To 999, Red LED
  • Surge Protection: 3 Transient/ Surge Absorbers
  • Maximum Surge Current: 6.5ka
  • Energy Absorption: 140 J
  • Sequential Outlet Switching Time: 1,2,3 or 4 Seconds
  • Sequential By-Pass: Yes
  • Lights : 2 Tubes with 4-Inch Extension. LED Array
  • Life of LED: +500,000 Hours
  • AC Filter Type: Emi
  • Noise Reduction: 9dB @ 10kHz, 41dB @ 100kHz, 102dB@ 10mHz
  • Internal Wiring: 12-Gauge
  • Construction: Black Steel Chassis
  • Power Consumption: 5 Watts

Specifications

Dimensions (H x W x D) 1.75" (44.45 mm) x 19" (483 mm) x 11" (280 mm)
Weight 11 lbs (4.99 kg)
