Inside the Design

This baseball stadium sound system provides quality sound reproduction with two weatherproof speakers for quality music and two long throw stadium horns for intelligible play-by-play announcements that can be heard in both the bleachers and on the field, perfect for little league, softball, baseball, and other athletic playing fields. The adjustable desktop stand and ultra-clear microphone is great for the announcers table in the press box. The crowd will appreciate the clear and intelligible speech from this high-performance audio system.

Key System Features:

• Easy to install and easy-to-use
• Weather resistant loudspeakers with dynamic sound quality and excellent intelligibility
• Wide coverage paging horns to provide coverage throughout the infield, outfield and bleachers
• High-quality audio for announcements, play-by-plays, paging and music
• Ultra Clear handheld mic with a quiet On/Off switch and desktop stand
• Cost-effective and high-performance 240W 5-channel mixer power amplifier



About the System Components

This affordable PA system for baseball fields includes two weather-resistant Community DS8 8" loudspeakers with dynamic sound quality and excellent intelligibility, as well as two JBL CSS-H15 paging horns for wider coverage that will reach to the infield, outfield and bleachers. Also included is the TOA A-2240 240W 5-channel mixer power amplifier for reliable paging and background music distribution, a Pure Resonance Audio UC1S Ultra-Clear™ dynamic vocal microphone with a super heavy-duty housing and ultra-quiet On/Off switch, a heavy-duty Atlas Sound DS7E mic stand, a 25ft microphone cable and 100ft of Aquaseal speaker wire to complete your installation.

Not sure if this is the right Stadium Sound System solution for you?
Call our sales team at (888) 256-4112 or click the Add to Quote button to request a customized sound system that fits your needs.

Community DS8 8" 2-Way Surface Mount Speakers:

• Modern architectural design
• Same components and voicing as the Distributed Design ceiling loudspeaker family
• High efficiency, high output, high intelligibility, low distortion
• Paintable enclosure constructed of high-impact ABS plastic to reduce resonances
• Front-accessible power tap switch for selectable 8 ohm or 70V/100V operation
• Infin-A-Ball™ low profile mounting bracket included
• Weather-resistant construction with treated drivers, two-layer powder coated grilles and protected wiring ingress
• Available in standard black or white finishes



JBL CSS-H15 15W Weather Resistant Paging Horn:

• Excellent voice range clarity for announcement and paging
• High sensitivity delivers high sound levels with minimal power amplification
• Wide 70° horizontal by 90° vertical coverage for medium throw applications
• Phenolic diaphragm driver for outdoor durability and high reliability
• UL-registered 15-watt multi-tap transformer, with 8 ohm direct bypass
• Built-in high-pass filter enhances reliability by protecting against low frequency damage
• Highly weather-resistant, with stainless steel bracket and hardware



TOA A-2240 240W Mixer Power Amplifier:

• Five Channel Integrated Mixer/Amplifiers for paging and background music distribution
• Proven TOA Quality and Reliability with wide frequency response, very low noise and distortion, and excellent output regulation
• Two Mic Inputs, balanced mic, inputs, 23 VDC phantom power switchable ON/OFF
• Two Auxiliary Inputs, unbalanced, stereo summing with dual-RCA jacks for convenient connection of stereo sources
• Transformer-Isolation for Telephone Paging Applications (Telephone Input)
• 25 V, 70.7 V and 4 Ohm Speaker Outputs with screw type barrier terminal strip
• Auto-Mute Priority Function
• Inputs Mic 1, Mic 2 and Telephone take priority
• Inputs Aux 1 and Aux 2 function as background inputs that mute -30dB during paging operation
• Auto-Mute Sensitivity Control for adjusting mute activation threshold
• Individual Channel and Master Volume Controls
• Bass/Treble Tone Controls
• Recording Output for connecting an external amplifier or recording device
• Over-current and Thermal Protection Circuitry prevents potential damage from overloads, short-circuit and overheating
• UL / cUL Listed



Pure Resonance Audio UC1S Ultra-Clear Dynamic Vocal Microphone with On/Off Switch:

• Super heavy-duty housing
• Built-in wind and breath "pop" noise filter
• Ultra dependable quiet switch
• Steel mesh grille
• SwitchCraft connector
• Frequency response tailored for vocals
• Uniform cardioid (unidirectional) dynamic pickup pattern isolates the main sound source and minimizes background noise
• Supplied with break-resistant stand adapter
• Frequency response: 50 to 16,000 Hz
• For outdoor and indoor events



Atlas Sound DS7E 8" - 13" Adjustable Height Desktop Mic Stand:

• Quality construction assures extended service and quality appearance
• Versatile stands fulfill functional and aesthetic miking requirements for microphone placement
• Weighted bases provide maximum stability

• (2) Community DS8 8" 2-Way Surface Mount Speakers
• (2) JBL CSS-H15 15W Weather Resistant Paging Horn
• (1) TOA A-2240 240W Mixer Power Amplifier
• (1) Pure Resonance Audio UC1S Ultra-Clear Dynamic Vocal Microphone with On/Off Switch
• (1) Atlas Sound DS7E Adjustable Height Desktop Mic Stand
• (1) XLR to XLR Microphone Cable - 25ft
• (100') West Penn AQ227 12/2 Aquaseal Fire-Alarm Speaker Wire
