Denon proudly presents this advanced DJ Mixer to audiophiles and music lovers as a further proof of Denon’s non-compromising pursuit of the ultimate in sound quality. The high quality performance and easy operation are certain to provide you with many hours of outstanding listening pleasure.
| Phono Inputs | 2 Stereo Unbalanced RCA jacks |
|---|---|
| Input Impedance | 50 kΩ/kohms |
| Level | –50 dBV (3 mV) |
| Line Inputs | 2 Stereo Unbalanced RCA jacks |
| Input Impedance | 20 kΩ/kohms |
| Level | –14 dBV (200 mV) |
| EQ Control (Line) | 3 Bands |
| Control Range | HI: –30 dB to +10 dB MID: –38 dB to +10 dB (at 1 kHz)LOW: –38 dB to +6 dB (at 60 Hz) |
| Mic Inputs | 1 Mono Active Balanced 1/4" TRS jack |
| Input Impedance | 2 kΩ/kohms |
| Level | –54 dBV (2 mV) |
| Frequency Response | 20 Hz to 20 kHz (±3 dB) |
| S/N | 66 dB |
| EQ Control (Mic) | 2 Bands |
| Control Range | HI: –12 to +12 dB (at 10 kHz)LOW: –12 to +12 dB (at 100 Hz) |
| Master Output | Specifications |
| Balanced | Stereo |
| Output Impedance | 150 Ω/ohms |
| Level | +4 dBm (1.23 Vrms) (600 Ω/ohms load) |
| Frequency Response | 20 Hz to 20 kHz (±2 dB) |
| THD+N | LINE: Below 0.05 % PHONO : Below 0.07 % |
| Cross Talk | Over 75 dB |
| Unbalanced | Stereo Unbalanced RCA jacks |
| Output Impedance | 1 kΩ/kohms |
| Level | 0 dBV (1 Vrms) (10 kΩ/ohms load) |
| Frequency Response | 20 Hz to 20 kHz (±2 dB) |
| THD+N | LINE : Below 0.05 % PHONO : Below 0.07 % |
| S/N | LINE : 85 dB PHONO : 76 dB |
| Cross Talk | Over 75 dB |
| Headphone Output | Stereo |
| Output Impedance | 33 Ω/ohms |
| Level | 0 dBV (1 Vrms) (32 Ω/ohms load) |
| Power Source | AC 10 V 750 mA x 2 |
| Power Supply, Consumptions | AC 120 V ± 10 %, 60 Hz (AC adaptor : AA-26) |
| Weight | 2.8 kg AC adaptor : 0.5 kg |
| Unit Size | 220 (W) x 232 (D) x 82.4 (H) mm |
