This product include features such as solid steel chassis construction, professional grade components and powerful USB MIDI capabilities make this a robust gigging tool, equally at home in the booth or the studio.
Ensuring the highest quality audio performance, the DN-X600’s internal sound card is a 4 x stereo in / 4 x stereo out 24-bit / 96kHz USB 2.0 Audio Interface, while the mixer’s audio output is via a whopping 32-bit DAC. The mixer’s vinyl credentials include a proprietary phono amp design with a signal-to-noise performance equivalent to that of the company’s top end hi-fi amplifiers, just as highly specified are the ultra-clean mic amp and high output headphone amp.
32-bit Floating Point DSP provides the mixer with powerful signal processing capabilities. 3-band channel EQ includes full kill on each band. On-board EFX include Delay, Echo, Flanger, Filter, Reverb, Loop, Beat Scratch and BeatBreaker, and the dedicated EFX section features ON/OFF, Dry-Wet mix and independent send assignment (Ch/Mic/Master). A powerful two-way EFX Parameter Filter, including Cross Over Frequency and Isolator (low pass filter/high pass filter) is included, as is a send/return control, for use with external effects.
The cross fader is a 45-mm High Performance Flex Fader with tension adjustment and a unique 32-point contour adjustment (and Innofader-Pro compatibility). Channel faders are 45-mm custom Alps-type, also with contour adjustment.
Extensive USB MIDI and audio interface and control capabilities enable use of the DN-X600 with the latest digital file library and DJ software solutions. The unit’s control surface is fully MIDI-mappable, including knobs, keys and buttons, and the DN-X600 can work with all current operating systems, including Mac OSX 10.6.4 and 32/64-bit Windows systems (XP, Vista, or Windows 7), a low-latency 32/64-bit ASIO driver is included for PC use.
| PHONO inputs | 2 StereoUnbalanced RCA terminal |
|---|---|
| Input impedance | 47 kΩ |
| Level | –40 dBV(10 mV) |
| Signal to Noise ratio | 89 dB |
| CD inputs | 2 StereoUnbalanced RCA terminal |
| Input impedance | 10 kΩ |
| Signal to Noise ratio | 100 dB |
| Equaliser (LINE) | 3 Band |
| HI (High Range) | –∞, –90 dB – +10 dB |
| MID (Medium Range) | –∞, –90 dB – +10 dB |
| LOW (Low Range) | –∞, –90 dB – +6 dB |
| AUX1 Input 1 Stereo | RCA Terminal |
| Input impedance | 10 kΩ |
| EFX RETURN AUX2 inputs | 1 Stereo RCA Terminal |
| Input impedance | 1 |
| EFX RETURN | –10 dBV |
| MIC inputs | Monaural |
| MIC | Balanced XLR(1: Ground, 2: Hot, 3: Cold) |
| Input impedance | 5kΩ |
| Level | –60 – +20 dBu |
| EIN | -126 dBu or less(Rs=150Ω) |
| CMRR | 89 dB or more (1 kHz) |
| Equaliser(MIC/AUX1) | 2 Band |
| HI (High Range) | –15 – +15 dB |
| LOW (Low Range) | –15 – +15dB |
| USB audio inputs | 4 Stereo(8 Monaural) 24 bit,Fs:44.1/48/96 kHzUSB B |
| MASTER output Balanced | Stereo, balanced XLR terminal(1: Ground, 2: Hot, 3: Cold) |
| DA converter | 32 bit 128-times oversamplingadvanced segment |
| Load impedance | Over 600 Ω |
| Level | + 4 dBu (Max + 24 dBu) |
| Frequency response | 20 Hz – 20 kHz(±0.5 dB) |
| THD | Less than 0.05% |
| Crosstalk | Less than –100 dB (1 kHz) |
| Unbalanced | Stereo RCA terminal |
| Load impedance | 1 |
| Level | 0 dBu (Max + 20dBu) |
| EFX SEND/BOOTH Output | Stereo RCA terminal |
| Load impedance | 10 kΩ or more |
| Level | Specifications |
| BOOTH | 0dBu (Max + 20dBu) |
| EFX SEND | –10dBV(Max +10dBV) |
| Load impedance | 40 Ω |
| Level | 100 mW |
| USB audio output | 4 Stereo(8 Monaural) 24bit,44.1/48/96 kHz USB B |
| USB MIDI I/O | IN:1ch, OUT:1ch MIDI1.0,MIDI Clock USB B |
| CH Meter | PPM 10 Point LED-20 – + 10dB, Peak |
| MASTER Meter | PPM 10 Point LED-20 – + 10dB, Peak |
| CH Fader | 45 mm Slim Type fader |
| Cross Fader | 45 mm FLEX Fader(Fader Torque Adjustable) |
| Power supply | AC 120 V, 60 Hz |
| Power consumption | 24 W(Less than 0.3 W during standby) |
| Operating temperature | +5 °C – +35 °C |
| Operating humidity | 25 % – 85 % |
| Storage temperature | –20 °C – 60 °C |
| Width | 250 mm / 9.8” |
| Height | 315 mm / 12.4” |
| Depth | 90 mm / 3.5” |
| Weight | 4.0 kg (8 lbs 13.1 oz) |
