Denon Professional DN-306XA 6 Channel Mixer Amplifier (Discontinued)

The DN-306XA is a basic 6-channel mixer with a built-in 120W Class-D amplifier in one rack space. Inputs are combo XLR/TRS jacks with switchable MIC, LINE, and phantom power. In addition to the amplified output on Euroblock speaker connectors, two XLR line outputs are included. The speaker output options are 4-Ohm, 70V-line and 100V-line. Added features include mic one priority and 3-band equalizer on the output.

• Six-channel mixer with 120W Class-D amplifier in one rack space
• XLR/TRS combo input jacks with phantom power
• Two XLR line outputs
• Euroblock speaker outputs support 4 Ohm, 70V-line and 100V-line
• Master level control and 3-band equalizer
• Mic one priority control

Cut Sheet
