DVDO C5-1-W 4K UHD 25x PTZ Camera with HDMI, SDI, USB, IP and AI Auto Tracking - White

Description

Details

DVDO C5-1-W 4K UHD 25x PTZ Camera in White

The C5-1-W 4K UHD PTZ camera in white delivers exceptional high-resolution video with advanced ISP processing for vivid colors, strong depth, and outstanding clarity. Its 25x optical zoom and 59.2° wide-angle lens provide flexible coverage for large rooms and critical AV applications, while multiple outputs, HDMI, SDI, USB 2.0, and IP, allow simultaneous connectivity for local recording, streaming, or control systems.

Equipped with AI human detection, the C5-1-W supports real-time tracking and zone tracking, ensuring accurate and automated monitoring of subjects. The camera also includes up to 255 presets, advanced 2D/3D noise reduction for low-light clarity, and dual-stream USB output for optimal near-end and far-end viewing.

Designed for professional environments, the C5-1-W is ideal for education, lecture capture, houses of worship, healthcare, tele-medicine, courtrooms, broadcasting, webcasting, live events, video conferencing, and command centers. Its white finish blends seamlessly into modern installations while maintaining a professional and unobtrusive appearance.

Features

Features

4K UHD resolution with high-quality Sony CMOS sensor, up to 60 fps
25x Optical zoom with 59.2° wide-angle lens and auto-focus
AI human detection with real-time and zone tracking
Up to 255 camera presets for rapid positioning
HDMI, SDI, USB 2.0, and IP outputs, all simultaneous
Dual-stream USB output for main and sub-stream viewing
LAN features, PoE power, H.264/H.265 video streaming, web GUI control
Supported network protocols, ONVIF, GB/T28181, RTSP, RTMP, VISCA over IP
Serial control interfaces, RS422-IN (compatible with RS485), RS232-IN/OUT, cascading support
Control protocols, VISCA, PELCO-D, and PELCO-P with automatic protocol detection
Low-noise 2D/3D noise reduction for high SNR image clarity
Ideal for classrooms, lecture halls, houses of worship, healthcare, courtrooms, broadcasting, and live events
Professional white finish blends seamlessly into ceilings and walls

Specification

Camera Resolution	4K UHD (3840x2160) up to 60 fps
Optical Zoom	25x
Lens	59.2° wide-angle, 7.1 - 171.95 mm focal length
Aperture/Iris	F1.61 - F5.19
Image Sensor	1/1.8 inch Sony CMOS, 8.51M effective pixels
Minimum Illumination	0.05 Lux (F1.8, AGC ON)
DNR	3D Digital Noise Reduction
White Balance	Auto/Manual/One Push/Specified Temperature
Focus Mode	Auto/Manual/One Push
Exposure Mode	Auto/Manual/Shutter Priority/Aperture Priority/Brightness Priority
Shutter Speed	1/25 - 1/10000 sec
Pan/Tilt Range	Pan: -110° - +110°, Tilt: -30° - +30°
Pan/Tilt Speed	Pan: 0.1°/s - 100°/s, Tilt: 0.1°/s - 70°/s
Preset Positions	Maximum 255 (10 via remote control)
AI Features	Real-time tracking, 4 regional tracking zones, human detection
Video Outputs	HDMI, SDI, USB 2.0, LAN (POE) simultaneous
Video Encoding	LAN: H.264/H.265, USB: MJPG/H.264/H.265/YUY2/NV12
Audio	Input: 3.5 mm dual track, Output: HDMI, LAN, USB 2.0, Compression: AAC, G.711A
Power	DC 12V ±10%, <1A, 12W consumption, HEC3800 connector, PoE support
Dimensions (H x W x L)	6.26" (159 mm) x 5.67" (144 mm) x 8.66" (220 mm)
Weight	3.75 lbs (1.7 kg)
