Dynasound DS3008 8-Channel DSP Sound Masking Processor (Discontinued)

The DS3008 is designed to provide sound masking, paging and music functions for centralized and networked sound masking systems. Each DS3008 provides four independent sound masking generators, each having 1/3 octave band equalization, adjustable high pass and low pass filters. Additionally, eight balanced line level inputs, eight balanced line level outputs and a matrix mixer facilitate configuring any mix of incoming signals with any of the sound masking generators and then routed to any of the outputs. Input processing includes per channel level control, equalization and configurable "soft-knee" compression. Output processing includes per channel level control for both analog and network audio. This feature provides unique functionality for use in traditional 70v. centralized systems, networked addressable systems, or systems combining both approaches.
