The transformer model CFID32T includes connections for 25V and 70V distributed systems and a screwdriver operated power tap select switch. A nominal 55° horizontal by 75° vertical coverage pattern, together with a low-frequency cutoff of 300 Hz, provides excellent articulation in demanding applications.
The CFID32T is molded from non-resonant and weatherproof Cycolac. Exclusive Uni-Lok swivel mount allows precision mounting in a variety of installations. The gland nut connection insures a weather-tight seal. Ideal for both indoor and outdoor applications, these drivers are well suited for any installation requiring rugged, reliable performance.
| Frequency Response | 330-4,200 Hz ±5 dB |
|---|---|
| Power Handling, 8 Hours, 6 dB Crest Factor | 32 W (500-5,000 Hz pink noise) |
| Impedance | 8 ohms |
| Sound Pressure Level | 107 dB |
| Horizontal Beamwidth | 55° @ 2 kHz |
| Vertical Beamwidth | 74° @ 2 kHz |
| Directivity Factor Rθ (Q) | 16.3 @ 2 kHz |
| Usable Low-Frequency Limit | 300 Hz |
| Construction | Non-resonant Cycolac horn material and durable diecast mounting bracket |
| Magnet Material | Strontium ferrite |
| Flux Density | 1.15 Tesla |
| Voice-Coil Diameter | 1.5" (38.1 mm) |
| Dimensions (H x W x D) | 7.1" (181 mm) x 14.4" (365 mm) x 12.5" (318 mm) |
| Magnet Weight | 0.63 lbs (0.28 kg) |
| Net Weight | 5.9 lbs (2.7 kg) |
| Shipping Weight | 6.3 lbs (2.9 kg) |
