The EVC-1181S-PIW is a high-performance 18-inch passive subwoofer designed to complement EVC full-range loudspeakers, including 8-, 12-, and 15-inch models. Its white, weather-resistant enclosure provides reliable performance in both indoor and outdoor installations. Engineered with a single high-output 18" low-frequency transducer and a 2.5-inch voice coil, the EVC-1181S-PIW delivers powerful, clear bass with a recommended frequency range of 30 Hz to 135 Hz, ideal for music, speech, and live events.
Constructed from 15-mm plywood with an EVCoat finish, the enclosure is built for durability and long-term reliability. The subwoofer includes multiple M10 rigging points for flexible floor or suspended installation and a gland-nut input cover for weather protection. It accepts wire gauges up to 10 AWG and can accommodate Euroblock or NL4 connectors for versatile system integration. For 70V/100V distributed systems, an optional TK150 transformer with Automatic Saturation Compensation preserves low-frequency performance even when driving multiple subwoofers in parallel.
The EVC-1181S-PIW does not include an internal passive crossover, requiring a suitable active low-pass filter and 4th-order high-pass filter for proper operation. This design allows precise system tuning to match EVC full-range loudspeakers, ensuring consistent, high-quality sound. With a maximum SPL of 129 dB and 350W continuous power handling, the EVC-1181S-PIW is an ideal solution for professional fixed installations, commercial venues, and performance environments requiring deep, controlled bass.
| Type | 18" passive subwoofer |
|---|---|
| LF Driver | 18" high-output low-frequency transducer, 2.5" voice coil |
| HF Driver | N/A (passive subwoofer) |
| Frequency Range | 30 Hz - 135 Hz (recommended) |
| Power Handling | 350W continuous/1400W peak |
| Sensitivity | 97 dB |
| Max SPL | 129 dB |
| Nominal Impedance | 8Ω |
| Crossover | Requires active low-pass & high-pass filters |
| Transformer Option | Optional TK150 for 70V/100V with ASC |
| Enclosure Material | 15-mm plywood with EVCoat finish |
| Rigging/Mounting | Multiple M10 points; floor or suspended installation |
| Connectors | Euroblock, optional NL4 or weatherized gland-nut adapters |
| Color | White |
| Applications | Indoor/outdoor fixed installations, PA, commercial venues, performance spaces |
| Dimensions (H x W x D) | 19.78" (503 mm) x 21.81" (554 mm) x 28.27" (718 mm) |
| Weight | 71.9 lbs (32.6 kg) |
| Shipping Weight | 80.5 lbs (36.5 kg) |
