Completely redesigned from the ground up, the all-analog Platinum Pro EQ universal instrument preamp delivers incredibly accurate sonic detail for any acoustic instrument. A discrete, high-headroom Class-A preamp uses precision, high-speed circuitry for the highest fidelity and low distortion. Classic Fishman tone centers with sweepable mid is combined with a switchable guitar/bass EQ mode, making it more musical for bass instruments and more universal for recording and performing musicians.
The new Platinum Pro EQ integrates critical performance features like adjustable volume boost and a balanced XLR D.I. output housed in a beautiful, road-ready design. The Platinum Pro EQ is built to be stomped on with durable foot switches that activate the adjustable volume boost or high-contrast chromatic tuner. It also includes a simple and effective analog soft-knee compressor, effects loop and precision sweepable notch filter.
| Nominal Input Level | -20dBV |
|---|---|
| Input Overload Level | +6dBV |
| Input Impedance | 10MW |
| ¼” Out | -23dBV + 3dBV (1kW ) |
| Tuner/Send Out | -.23dBV + 3dBV(1kW ) |
| XLR Out | -32dBV -6dBV (600W ) |
| Bass Control Range | ±12dB at 60Hz,±3dB at 350Hz |
| Treble Control Range | ±12dB at 10kHz,±3dB at 2.4kHz |
| Mid Control Range | ±12dB (adjustable from250Hz to 5kHz) Q=0.5 |
| Brilliance Control Range | ±9dB at 10kHz,±3dB bandwidth 7kHz |
| THD | Less than .02%, -10dBV input |
| Signal to Noise Ratio | 90dB (A weighted, -10dBV input,2dBV ¼”output) |
| Power Supply | 9V alkaline battery |
| Current Draw | 4.7mA |
