Galaxy Audio JIB/MM Jacks in the Box 4-Channel Multi Mixer (Discontinued)

The Galaxy Audio JIB/MM 4-channel multi mixer is a great tool for live sound, home recording, field recording, audio/video, and more. It is great for use in churches, schools, and bands. This unit features 4 inputs; Channel 1 & 2: XLR/1/4" combo with 20dB pad, Channel 3: Stereo RCA and Stereo 1/8" mini (3.5mm), Channel 4: Stereo RCA. Each channel has its own volume control. The JIB/MM also features numerous outputs; XLR, 1/4", stereo RCA, and a stereo headphone output with a volume control. The "Mic/Line switch" located between the XLR and 1/4" Balanced Mono Outputs allows for selecting either a "Mic Level" Balanced Mono Output or a "Line Level" Balanced Mono Output. The JIB/MM runs off of 2 AA batteries for about 15 hours or an optional DC power supply (JIB/UA4.5-14). The JIB/MM supplies +24V phantom power to microphones.

The JIB/MM is great for:

• Adding inputs to an existing mixer by creating a sub-mix of two or more sources before sending the signals to the main mixer or powered speaker.
• Serving as a sophisticated cable adapter that not only adapts the connector type but also provides the correct impedance with adjustable level control.
• Serving as the main mixer for solo or duo acts as well as AV presentations.
• As a mixer for rehearsals when it is impractical to set up the entire PA.
• Interfacing pro audio gear with consumer audio gear.
• Battery operation allows remote location use where AC power is unavailable.
• As an emergency backup mixer to have along just in case.

• +24V phantom power
• 7 input/4 channel
• Headphone output with volume
• Multiple outputs
• Metal construction
• Portable - runs off of 2 AA batteries
• High gain/wide dynamic range
