- Description
Details
The Harman Kardon® AVR 2700 audio/video receiver has the immense connectivity and astonishing sound output to turn your living room into the kind of home entertainment center once reserved for movie moguls and dotcom billionaires. Its eight HDMI® inputs, including one input on the front panel and 4K compatibility, ensure connectivity to all of your Blu-ray™ disc, HDTV and video-game sources, while its analog and digital audio input jacks keep you connected to all your legacy components. Built-in AirPlay and DLNA® 1.5 certified connectivity empower you to play almost every song on your computer, tablet and mobile devices and do it in surround sound regardless of the number of channels in the original recording, thanks to our exclusive Logic 7 processing. To top it all off, an intuitive, high-definition menu system, remote control, available mobile app and EzSet/EQ™ calibration make operation and setup seem too easy for a device this advanced. Powered by an eco-friendly, digital power supply that delivers superior performance and 100 watts per channel without the weight of conventional designs, this receiver will not only fill your room with crisp, clear Harman Kardon sound but also make you feel as though you are with the musicians or filmmakers who are creating it. Just think of the AVR 2700 as your personal concierge, eager to help you enjoy virtually any entertainment you like.
- Features
Features
- 100W per channel
- Eight HDMI inputs with 3D and Audio Return Channel, including one on the front panel, and two HDMI inputs
- 7.1-Channel surround sound
- Dolby TrueHD and DTS-HD Master Audio decoding
- Multizone functionality
- Dolby Volume
- DLNA Certified 1.5 connectivity
- AirPlay audio streaming
- High-definition user interface
- 4K video pass-through and upscaling
- EzSet/EQ technology (maximizes sonic performance)
- Specification
Audio Section Stereo and Multichannel Power 105W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.07% THD Input Sensitivity/Impedance 200mV/47k ohms Signal-to-Noise Ratio (IHF-A) 100dB Surround System Adjacent Channel Separation Dolby Pro Logic/DPLII: 40dB
Dolby Digital: 55dB
DTS: 55dBFrequency Response (@ 1W) 10Hz – 130kHz (+0dB/–3dB) High Instantaneous Current Capability (HCC) ±39 amps Transient Intermodulation Distortion (TIM) Unmeasurable Slew Rate 40V/μsec FM Tuner Section Frequency Range 87.5MHz–108.0MHz Usable Sensitivity (IHF) 1.3μV/13.2dBf Signal-to-Noise Ratio (Mono/Stereo) 70dB/68dB Distortion (Mono/Stereo) 0.2%/0.3% Stereo Separation 40dB @ 1kHz Selectivity (±400kHz) 70dB Image Rejection 80dB IF Rejection 80dB AM Tuner Section Frequency Range 522 – 1620kHz Signal-to-Noise Ratio 38dB Usable Sensitivity (Loop) 500μV Distortion (1kHz, 50% mod) 1.0% Selectivity (±10kHz) 30dB Video Section Television Format PAL Input Level/Impedance 1Vp-p/75 ohms Output Level/Impedance 1Vp-p/75 ohms Video Frequency Response (Composite Video) 10Hz – 8MHz (–3dB) HDMI Support up to 4k x 2k General Specifications Power Requirement 220V – 240V AC/50Hz – 60Hz Power Consumption <0.5W (standby); 370W Maximum Dimensions (H x W x D) 6.5" (165 mm) x 17.94" (440 mm) x 17.13" (435 mm) Weight 16.9 lbs (7.7 kg) - Documents
