Harman Kardon AVR 2700 7.1 Channel A/V Receiver (Discontinued)

Part # AVR 2700
Model # AVR 2700

The Harman Kardon® AVR 2700 audio/video receiver has the immense connectivity and astonishing sound output to turn your living room into the kind of home entertainment center once reserved for movie moguls and dotcom billionaires.

Description

Details

The Harman Kardon® AVR 2700 audio/video receiver has the immense connectivity and astonishing sound output to turn your living room into the kind of home entertainment center once reserved for movie moguls and dotcom billionaires. Its eight HDMI® inputs, including one input on the front panel and 4K compatibility, ensure connectivity to all of your Blu-ray™ disc, HDTV and video-game sources, while its analog and digital audio input jacks keep you connected to all your legacy components. Built-in AirPlay and DLNA® 1.5 certified connectivity empower you to play almost every song on your computer, tablet and mobile devices and do it in surround sound regardless of the number of channels in the original recording, thanks to our exclusive Logic 7 processing. To top it all off, an intuitive, high-definition menu system, remote control, available mobile app and EzSet/EQ™ calibration make operation and setup seem too easy for a device this advanced. Powered by an eco-friendly, digital power supply that delivers superior performance and 100 watts per channel without the weight of conventional designs, this receiver will not only fill your room with crisp, clear Harman Kardon sound but also make you feel as though you are with the musicians or filmmakers who are creating it. Just think of the AVR 2700 as your personal concierge, eager to help you enjoy virtually any entertainment you like.

Features

Features

  • 100W per channel
  • Eight HDMI inputs with 3D and Audio Return Channel, including one on the front panel, and two HDMI inputs
  • 7.1-Channel surround sound
  • Dolby TrueHD and DTS-HD Master Audio decoding
  • Multizone functionality
  • Dolby Volume
  • DLNA Certified 1.5 connectivity
  • AirPlay audio streaming
  • High-definition user interface
  • 4K video pass-through and upscaling
  • EzSet/EQ technology (maximizes sonic performance)
Specification
Audio Section
Stereo and Multichannel Power105W per channel, two channels driven @ 6/8 ohms, 20Hz – 20kHz, <0.07% THD
Input Sensitivity/Impedance200mV/47k ohms
Signal-to-Noise Ratio (IHF-A)100dB
Surround System Adjacent Channel SeparationDolby Pro Logic/DPLII: 40dB
Dolby Digital: 55dB
DTS: 55dB
Frequency Response (@ 1W)10Hz – 130kHz (+0dB/–3dB)
High Instantaneous Current Capability (HCC)±39 amps
Transient Intermodulation Distortion (TIM)Unmeasurable
Slew Rate40V/μsec
FM Tuner Section
Frequency Range87.5MHz–108.0MHz
Usable Sensitivity (IHF)1.3μV/13.2dBf
Signal-to-Noise Ratio (Mono/Stereo)70dB/68dB
Distortion (Mono/Stereo)0.2%/0.3%
Stereo Separation40dB @ 1kHz
Selectivity (±400kHz)70dB
Image Rejection80dB
IF Rejection80dB
AM Tuner Section
Frequency Range522 – 1620kHz
Signal-to-Noise Ratio38dB
Usable Sensitivity (Loop)500μV
Distortion (1kHz, 50% mod)1.0%
Selectivity (±10kHz)30dB
Video Section
Television FormatPAL
Input Level/Impedance1Vp-p/75 ohms
Output Level/Impedance1Vp-p/75 ohms
Video Frequency Response (Composite Video)10Hz – 8MHz (–3dB)
HDMISupport up to 4k x 2k
General Specifications
Power Requirement220V – 240V AC/50Hz – 60Hz
Power Consumption<0.5W (standby); 370W Maximum
Dimensions (H x W x D)6.5" (165 mm) x 17.94" (440 mm) x 17.13" (435 mm)
Weight16.9 lbs (7.7 kg)
