JBL STX812M 12 inch Stage Monitor (Discontinued)
Part # STX812M
Model # STX812M

The JBL STX812M is designed specifically to be a high performance 12" 2-way floor monitor, it can also do double duty as a utility speaker for use on a tripod stand or over a subwoofer, utilizing a single-position pole mount.

Need Quantity Pricing?

We provide quantity discounts for contractors & installers, schools, government, and military buyers on select brands and products.

Talk To An Engineer

Description

Details

Designed specifically to be a high performance 12" two-way floor monitor, it can also do double duty as a utility speaker for use on a tripod stand or over a subwoofer, utilizing a single-position pole mount. A 70 degree by 70 degree waveguide is utilized for precise coverage.

Features

Features

  • Compact and low-profile for minimal obstruction of audience sight-lines
  • 70°x 70° nominal coverage
  • Bi-amplified or full-range passive operation
  • Pole socket for applications requiring pole or tripod mounting
  • High power handling, low distortion Vented Gap Cooling™ LF driver
  • 3 in. (diaphragm) neodymium magnet compression driver
  • Rugged DuraFlex™ coated enclosures sized to be truck pack friendly
  • 14-Gauge steel grille lined with acoustically transparent cloth
Specification
Frequency Range ( –10 dB)50 Hz-20 kHz
Frequency Response (± 3 dB)75 Hz-20 kHz
Coverage Pattern70˚ × 70˚ nominal
Sensitivity (1W/1m)95 dB
Power Rating600W / 1200W / 2400W (Continuous/Program/Peak)
Rated Maximum SPL129 dB SPL Peak
Nominal Impedance
Input ConnectorsTwo NL4
Operational ModesFull Range/Bi-Amp
Dimensions (H x W x D)22.5" (571 mm) x 13.4" (355 mm) x 10.4" (264 mm)
Net Weight40 lbs (18 kg)
