| Frequency Range (-10 dB) | 55 Hz – 22 kHz |
|---|---|
| Frequency Response (+/- 3 dB) | 67 Hz – 20 kHz |
| Horizontal Coverage Angle (-6 dB) | 100 degrees nominal (500 Hz – 16 kHz) |
| Vertical Coverage Angle (-6 dB) | Varies with array size and configuration |
| System Input Power Rating | LF: 1000W Continuous, 4000W Peak (AES/2 hour), MF/HF: 225W Continuous, 900W Peak (AES/2 hour) |
| Maximum Peak Output | 131 to 141 dB SPL, 1m (frequency/bandpass dependent) |
| Recommended Amplification | LF: 1000–2000W into 8 ohms MF/HF: 450–900W into 8 ohms |
| Recommended Signal Processing | dbx® 4800, Crown® I-Tech, BSS FDS-366T, and other Digital System Controllers supported |
| Low Frequency | Two 2168J-1, 203 mm (8 in) dia., 76 mm(3 in) Dual Coil, Neodymium Differential Drive®, Direct Coole |
| Bandpass Nominal Impedance | 8 ohms (16 ohms each transducer, wired in parallel) |
| Input Power Rating | 1000W Continuous, 4000W Peak (AES/2 hour) 700W Continuous, 2800W Peak (100 hour) |
| Bandpass Sensitivity | 97 dB, 1W / 1m (2.83 Vrms at 3.3 ft) |
| Mid & High Frequency | MID: Four 2104H, 101 mm (4 in) with 25.4 mm (1 in) dia. voice coil |
| Mid & High Frequency: | HIGH: Two 2408H, 25 mm (1 in) exit compression driver, 38 mm (1.5 in) voice coil |
| Bandpass Nominal Impedance | 8 ohms (drivers wired in series-parallel, passive network) |
| Input Power Rating2 | 225W Continuous, 900W Peak (100 hour) |
| Bandpass Sensitivity | 103 dB, 1W / 1m (2.83 Vrms at 3.3 ft) |
| Box Construction | Wedge frustum 5 degree side angle enclosure. PlyMax® engineered wood composite structure |
| Suspension System | S.A.F.E. hardware, integral hinge bars nest in rigging tubes on box ends |
| Grille | Black perforated steel, foam backed |
| Input Connectors | Neutrik® Speakon® NL-8 and NL-4 (2x each), Pin 3+/- forLows & Pin 4+/- for Mid-Highs |
| Dimensions (H x W x D) | 11" (281 mm) x 31" (787 mm) x 16.3" (415 mm) |
| Net Weight | 67 lbs (30.4 kg) |
| Shipping Weight | 90 lbs (40.8 kg) |
